4*2 FOTON Fecal Tank Truck

Chengli Special Automobile Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Transmission Type:

Automatic

Condition:

New

Emission Standard:

Euro 3

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Automatic

Condition New

Emission Standard Euro 3

Fuel Type Diesel

Tank Volume 2620L

Dimension (L x W x H) 5650*1900*2300mm

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5050GXE3

Horsepower 90

Gross Vehicle Weight 5495

4*2 FOTON fecal tank truck

Specifications:

Product	Fecal Suction Truck
Vehicle model	CLW5050GXE3
Chassis model	EQ1050TJ20D2
Kerb weight	3365 kg
Chassis parameters	Overall dimensions	mm			5650×1900×2300
	Tank dimensions				3000×1360×960
	Gross weight	kg			5495
	Rated payload				2000
	Approach/Departure angle	°			19/13
	Suspension F/R	mm			1082/1568
	Wheel base				3000
	F/R tread				1404,1460/1458
	Drive type				4*2
	Number of axles				2
	Axle-load	Kg			2180/3315
	No. of Spring leaf				6/8+4,8/9+5
	Clutch				uniwafer ,dry clutch, hydraulic remote control
	Braking system				Air braking
	Steering gear				recirculating ball type steering wheel
	Tire specification				7.00-16,6.50-16,7.00R16,6.50R16
	No. of Tires				6
	Electric system				24v
	Allowable passengers in cab				3
	Air-condition				Optional
Engine	Engine model				YC4F90-30
	Type of fuel				Diesel
	Displacement			ml	2659
	Hp/Power				90/66
	Operation control system				Power Steering
	transmission				6-speed with over drive
	Max speed		Km/h		90
	Manufacturer				Guangxi Yuchai Machine Co., Ltd
	Emission standard(TAS)				EURO 3
Special performance & Equipment	1, Equipped with vacuum pump(rating rotate speed=1400r/m, min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise) 2, Equipped with power take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment 3, Time for full suction<5min
Production cycle	7-10
