Specifications
Yuejin Truck Mounted Vacuum Loader4x2 drive
engine power 120ps
factory sale
short lead time
Yuejin Truck Mounted Vacuum Loader
Our vacuum loader are mounted on good quality and certified chassis /cabs , ideal for emptying of septic tanks surcharged manholes , gulley pits for both liquid , solids and slurry materials.
Vehicle name | Truck Mounted Vacuum Loader | ||
Manufacturer | Hubei Jiangnan Special Automobile Co., Ltd | ||
Cabin | Single row with sleeper bed , 3 seats | ||
Drive type | 4x2, left hand drive | ||
Wheel base | 3800 mm | ||
Overall dimension (L*W*H) | 6200×2090×2600 mm | ||
Weight | GVW | 9495 kg | |
Curb weight | 5300 kg | ||
Payload weight | 4000 kg | ||
Engine | Engine model | CA4DC2-12E3 | |
Make | Deutz (Dalian) Engine Co., Ltd | ||
Rated power / Displacement | 88 kw /3168 ml | ||
Engine type | Diesel engine , 4-cylinders in line | ||
Emission standard | Euro 2 | ||
Wheel track (F/ R) | 1780 / 1586 | ||
Tire type | 7.500-16 , 6pcs | ||
Vacuum tanker volume | 6cbm | ||
Tanker material | Carbon steel or stainless steel | ||
Max pressure of hydraulic system | 16MPa | ||
The images of truck mounted vacuum loader :
Our factory main products:
fire trucks , aerial working truck , garbage truck , cesspit emptier / vacuum loaders , fecal sucking truck , truck mounted crane , refrigerated truck , road sweeper , van truck , cargo truck , road wrecker / recovery truck / tow truck , semi-trailer, tractor , dump truck , concrete mixer truck.........
