DongFeng 35000L Bulk Cement Tank Truck

Chengli Special Automobile Co., Ltd.

US$ 45,999 - 89,999 MOQ: 1 Set

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

CLW

Model Number:

CLW5310GFL

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5310GFL

Gross Vehicle Weight 31000

Specifications

bulk cement tank truck
Discharging Hose Length ,6,000 mm
Discharging capacity>1,200 Kg/min
Working pressure,0.2 Mpa.

bulk cement tank truck

Item	unit	parameter
Vehicle		Bulk Cement Tanker CLW5310GFL
Chassis model		EQ1290WJ
Overall dimensions	mm	11990×2595×3800
Tank Volume	M³/T	35 m³ / 40T
Body internal dimensions	mm	9000/2300/1800
Wheel base		1900+5000+1300
F/R track base		1940 / 1830
Approach/departure angle	°	19/19	Engine type	C260-20
Exhaust/hp	ml/hp	8300/260	Traction system	8×4
Max speed	km/h	90	Transmission	9-speed with over drive
Tire specification	11.00-20
Number of axles	4		Electric system	24v
Operation control system	Electrically hydraulic control		Allowable passengers in cab	3
Engine type	Cummins Environmentally friendly, supercharge, diesel engine
Equipment	Meterial:6mm carbon steel. Discharging Hose, 4 inch Discharging Hose Length ,6,000 mm Discharging capacity≥1,200 Kg/min Working pressure,0.2 Mpa. MAX Horizontal Discharging Distance, 5,000 mm MAX. Vertical Discharging Distance,25,000 mm. 1m³=1.2T~1.3T cement Diesel Engine , 4100AG Made in China. Air Compressor , WB-10/2, Made in China,8M³
Production cycle	30-35 days
