Mini Electric Golf Cart in Golf Course

Mini Electric Golf Cart in Golf Course thumbnail-1
Mini Electric Golf Cart in Golf Course photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Eagle
Model Number:
EG2046K
Contact Supplier Request Quote Chat Now
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Eagle
Model Number EG2046K
Type Other

Mini electric golf cart in golf course

Product Description



Model EG2046K EG2046K01 EG2046K02 EG2046K03 EG2046K05 EG2046K07 EG2046K08 EG2046K09
System 48V/3KW Sepex 48V/4KW Sepex 48V/4KW Sepex 36V/3KW Sepex 48V/5.3KW Sepex 48V/3KW AC System 48V/5KW AC System 48V/5KW Sepex
Key Components
Battery 6PCSxT875(145Ah@5hr rate) 6PCSxT875(145Ah@5hr rate) 8PCSxT105(185Ah@5hr rate) 6PCSxT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate)
Motor 3KW ADC motor  3.8KW Chinese motor 3.8KW Chinese motor 3KW ADC motor 5.3KW Chinese Motor 3KW German Motor 5KW Chinese Motor 5KW ADC DV9 Motor
Controller Curtis 1266 (275A@2minutes Curtis 1268 (400A@2minutes) Curtis 1268 (400A@2minutes) Curtis 1243 (300A@2minutes) Curtis 1268 (400A@2minutes Zapi ACE0((280A@2minutes) Zapi ACE2(400A@2minutes Curtis 1268 (400A@2minutes
Performance
Passenger capacity 4 4 4 4 4 4 4 4
Range (loaded) based on flat road at a speed of 20km/h (km)* >55 >55 >80 >55 >80 >105 >105 >80
Max. speed @12.76:1 gear ratio 25 32 32 21 32 32 32 32
Max. speed @10.26:1 gear ratio 32 40 40  --  --  --  --  --
Minimum turning radius (m) 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Max. climbing ability (loaded)   @ 12.76:1 gear ratio 25% 25% 25% 20% 25% 25% 25% 25%
Max. climbing ability (loaded)   @ 10.26:1 gear ratio 15% 20% 20%  --  --  --  --  --
Max. movement after brake at speed of 20km/h ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m
Max. loading weight 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs
Net weight 542kgs 544kgs 592kgs 534kgs 592kgs 592kgs 601kgs 590kgs
Dimensions
Overall dimensions (mm) 3150X1180X1850
Min. ground clearance (mm) 120
Wheelbase (mm) 2450
Front wheel tread (mm) 855
Rear wheel tread (mm) 975
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Frame Welded steel framework with phosphate+electro-coating treatment
Body PP plastic front body + PP plastic rear body
Roof Fibreglass
Plastic
Windshield one-piece Organic glass
Windshield, hinged
Stainless steel package including front upright, rear upright, sweater basket and bracket
2point seat belt
Large Seats:
     1) backrest and cushion Rebond seat + artificial leather
     2) armrest Formed
     3) plastic seat bottom Last row of seat
Backrest cover in wood finish
Floor rubber
Center storage basket Large volume
Golf bag holder
Dashboard in black plastic forward/reverse switch, battery capacity indicator, ignition key
Dashboard in wood finish
Steering wheel in wood finish
Beverage holders  4 cups drink holders
Glove box
Side trim  plastic
Score card holder on steering wheel
Towing bracket  on front of golf car
Inner rear view mirror 1 piece per cart in the middle of the windshield
Side rear view mirror Two pieces per cart
Battery watering system,48V system without water supply tool
Battery watering system,36V system without water supply tool
Manual Pump water supply tool (other water supply tools are available)
Overshadowing Curtain
Enclosure
Electric system
Lighting system and horn 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Reversing alarm
Police Light
12V accessory plug to be mounted on the dashboard
Hour meter
Solar Panel 48V, 185W
Cooler 12V DC, 6L
Charger China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A
Steering and Suspension
Steering system Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system Mechanical brake
4-wheel hydraulic brake + hand brake
4-wheel hydraulic brake, front disc brake, rear drum brake
Accelerator Stepless speed change
Suspension system Front and rear plate spring + cylinder hydraulic shock absorber
Driving mode Rear axle two stage deceleration, motor direct driving
Rear axle Integrated, Gear ratio 12.76:1
Integrated, Gear ratio 10.26:1
Wheel & Tyre 10x6 Alumimum wheel & 205/50-10 4PR
6J-10 steel wheel with cap & 205/50-10 4PR
8*7 steel wheel with cap & 18*8.5-8 6PR



Model EG2046K EG2046K01 EG2046K02 EG2046K03 EG2046K05 EG2046K07 EG2046K08 EG2046K09
System 48V/3KW Sepex 48V/4KW Sepex 48V/4KW Sepex 36V/3KW Sepex 48V/5.3KW Sepex 48V/3KW AC System 48V/5KW AC System 48V/5KW Sepex
Key Components
Battery 6PCSxT875(145Ah@5hr rate) 6PCSxT875(145Ah@5hr rate) 8PCSxT105(185Ah@5hr rate) 6PCSxT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate) 8xT105(185Ah@5hr rate)
Motor 3KW ADC motor  3.8KW Chinese motor 3.8KW Chinese motor 3KW ADC motor 5.3KW Chinese Motor 3KW German Motor 5KW Chinese Motor 5KW ADC DV9 Motor
Controller Curtis 1266 (275A@2minutes Curtis 1268 (400A@2minutes) Curtis 1268 (400A@2minutes) Curtis 1243 (300A@2minutes) Curtis 1268 (400A@2minutes Zapi ACE0((280A@2minutes) Zapi ACE2(400A@2minutes Curtis 1268 (400A@2minutes
Performance
Passenger capacity 4 4 4 4 4 4 4 4
Range (loaded) based on flat road at a speed of 20km/h (km)* >55 >55 >80 >55 >80 >105 >105 >80
Max. speed @12.76:1 gear ratio 25 32 32 21 32 32 32 32
Max. speed @10.26:1 gear ratio 32 40 40  --  --  --  --  --
Minimum turning radius (m) 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Max. climbing ability (loaded)   @ 12.76:1 gear ratio 25% 25% 25% 20% 25% 25% 25% 25%
Max. climbing ability (loaded)   @ 10.26:1 gear ratio 15% 20% 20%  --  --  --  --  --
Max. movement after brake at speed of 20km/h ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m ≤4m
Max. loading weight 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs 370kgs
Net weight 542kgs 544kgs 592kgs 534kgs 592kgs 592kgs 601kgs 590kgs
Dimensions
Overall dimensions (mm) 3150X1180X1850
Min. ground clearance (mm) 120
Wheelbase (mm) 2450
Front wheel tread (mm) 855
Rear wheel tread (mm) 975
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Frame Welded steel framework with phosphate+electro-coating treatment
Body PP plastic front body + PP plastic rear body
Roof Fibreglass
Plastic
Windshield one-piece Organic glass
Windshield, hinged
Stainless steel package including front upright, rear upright, sweater basket and bracket
2point seat belt
Large Seats:
     1) backrest and cushion Rebond seat + artificial leather
     2) armrest Formed
     3) plastic seat bottom Last row of seat
Backrest cover in wood finish
Floor rubber
Center storage basket Large volume
Golf bag holder
Dashboard in black plastic forward/reverse switch, battery capacity indicator, ignition key
Dashboard in wood finish
Steering wheel in wood finish
Beverage holders  4 cups drink holders
Glove box
Side trim  plastic
Score card holder on steering wheel
Towing bracket  on front of golf car
Inner rear view mirror 1 piece per cart in the middle of the windshield
Side rear view mirror Two pieces per cart
Battery watering system,48V system without water supply tool
Battery watering system,36V system without water supply tool
Manual Pump water supply tool (other water supply tools are available)
Overshadowing Curtain
Enclosure
Electric system
Lighting system and horn 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Reversing alarm
Police Light
12V accessory plug to be mounted on the dashboard
Hour meter
Solar Panel 48V, 185W
Cooler 12V DC, 6L
Charger China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A
Steering and Suspension
Steering system Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system Mechanical brake
4-wheel hydraulic brake + hand brake
4-wheel hydraulic brake, front disc brake, rear drum brake
Accelerator Stepless speed change
Suspension system Front and rear plate spring + cylinder hydraulic shock absorber
Driving mode Rear axle two stage deceleration, motor direct driving
Rear axle Integrated, Gear ratio 12.76:1
Integrated, Gear ratio 10.26:1
Wheel & Tyre 10x6 Alumimum wheel & 205/50-10 4PR
6J-10 steel wheel with cap & 205/50-10 4PR
8*7 steel wheel with cap & 18*8.5-8 6PR



Packaging & Shipping

 Mini electric golf cart in golf courseMini electric golf cart in golf course



Company Information

 Mini electric golf cart in golf course



Certifications

 Mini electric golf cart in golf course



After-Sales Service



All electric golf carts sold by us are quality guaranteed.

We provide 13 months warranty to our electric vehicles from the shipping date.
