Chinese Electric solar Golf Cart for golf clubs

Name: Chinese Electric solar Golf Cart for golf clubs
Price: Negotiable

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 2000 Unit / Units per Month
Port Shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Seats:	3 - 4	Fuel Type:	Electric	Battery Voltage:	48V
Certification:	CE

Product Description

Electric Golf Car for golf clubs

Product Description

Specifications	Model	EG2048K
Key Components	Power Source	Pure Electric
	Electric System	Both AC and DC system are available
	Battery	Trojan battery
	Motor	ADC motor or Chinese Motor
	Controller	Curtis controller
	Charger	China origin, input 110V-240V~50Hz-60Hz,
Performance	Passenger capacity	4
	Range (loaded) based on flat road at a speed of 20km/h (km)^*	Up to 100
	Max. speed	Up to 40
	Minimum turning radius (m)	4.5
	Max. climbing ability (loaded)	Up to 25%
	Max. movement after brake at speed of 20km/h	≤4m
	Max. loading weight	320kgs
Dimensions	Overall dimensions (mm)	3110X1180X1890
	Min. ground clearance (mm)	120
	Wheelbase (mm)	2450
	Front wheel tread (mm)	855
	Rear wheel tread (mm)	975
Body and Frame	Frame	Welded steel framework with phosphate+electro-coating treatment
	Body	PP plastic front body + PP plastic rear body
	Roof	Injected plastic
Electric system	Lighting system and horn	Headlights,front turn signals, taillights, with DC-DC converter, horn,reversing alarm
Steering and Suspension	Steering system	Single-stage rack and pinion steering system, automatic rocker compensating function
	Brake system	Mechanical brake
	Suspension system	Front and rear plate spring + cylinder hydraulic shock absorber
	Driving mode	Rear axle two stage deceleration, motor direct driving
	Rear axle	Integrated,
	Wheel & Tyre	Alumimum wheel & 205/50-10 Tyre
Options	Hinged Windshield
	Stainless steel package
	Meter(available for 48V system)
	2 point seat belt
	Formed seat&backrest vinyl
	Wood finish Package
	Inner & Side rear view mirror
	Solar Panel
	Cooler
	on-body charger
	Right hand drive system
	4-wheel hydraulic brake system
	Enclosure
Body Color	Up to 6 kinds of standard color for option
Loading	Both Assembly and Disassembly are available

Color

Packaging & Shipping

Vehicle will be packed in steel rack

Container loading qty	Semi-knock-down
20'ft GP	4
40'ft GP	12
40'ft HQ	18

Our Services

All electric vehicles sold by us are quality guaranteed.

We provide 13 months warranty to our electric vehicles from the shipping date.
