#13-2 Solar Cane Best Quality Chinese Excavator for Sale by Courier LC

US$ 97,000 - 100,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

TNN

Model Number:

T220-7A

The TNN Development Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name TNN

Model Number T220-7A

Condition New

Moving Type Crawler Excavator

Operating Weight 21800

Bucket capacity 0.92m3

Maximum Digging Height 9960mm

Maximum Digging Depth 6600mm

Machine Weight 21800 kg

Max Digging Radius 9940mm

Rated Speed 4.8/3.3km/h

Certification CE

After-sales Service Provided Overseas third-party support available

Specification

Specification of 22tons excavator with cabin

Loading
Nude packing			Roller vessel

Specification of T220-7A/T220-8c with cabin
Operate weight kg		21800
Bucket capacity M3		0.92
T220-7A	Engine model	Cummins 6B5.9-C
	Engine power (kw)	112kw/1950rpm
T220-8C	Engine model	ISUZU 6BG1TRP-02
	Engine power (kw)	120kw/2150rpm
Ground pressure (Kpa)		45
Travel speed (km/h)		4.8/3.3
Gradeability (°)		35
Arm digging force (KN)		115
Fuel tank capacity(L)		410
Hydraulic tank capacity(L)		230
Main dimensions
Upperstrcuture witdth (mm)		2700
Undercarriage width (mm)		2810
Cabinet hight (mm)		3010
Rear swing radius mm)		2940
Track gauge (mm)		2210
Ground clearance (mm)		465
Working range
Max.digging reach mm)		9940
Max.digging depth (mm)		6600
Max.digging height (mm)		9960
Max.dumping height (mm)		7135
Max.vertical wall digging depth (mm)		6100
Min,swing radius (mm)		3203
Standard Equipment T220-7A
Japanese Kawasaki main pump
US Parker valve,tracking motor
US Eaton seing motor,travel motor
Italian valve ,pilot control lever
Standard Equipment T220-8C
Japanese Kawasaki main pump
Japanese KYB valve,tracking motor
Japanese Kawasak swing motor
Italian valve ,pilot control lever

Warranty,Payment and Delivery
Warranty Term: 1200 working hours or 1 year, whichever come first
Payment Term: 100% T/T or Irrevocable L/C payable at sight
Time of delivery: 30 days for models with standard equipment, after receipt of L/C or 30% T/T down payment.
