Help CenterNEW Lonking 5 Ton Payloader 856
Related Products
-
LONKING Wheel Loader 856 Earthmoving MachineUS$ 40,000 - 70,000MOQ: 1 Unit -
1.5CBM 3 Ton Mini Wheel Loader With Good PriceNegotiableMOQ: 1 Unit
-
Most Popular 5ton Loader in Middle East MarketNegotiableMOQ: 1 Unit
-
Cheap Price Poplular Mini Wheel Loader SL18DNegotiableMOQ: 1 Unit
-
Manual Control SEM Brand 3Ton Wheel Loader for SaleUS$ 20,000 - 40,000MOQ: 1 Unit
| Overall Data | Steering System | ||||||||||||
| Bucket Capacity (m3) | 3 | Type | Hydraulic Load Sensing System | ||||||||||
| Rated Payload(kg) | 5000 | Cylinders-bore×Stroke(mm) | 2-100×324 | ||||||||||
| Operating Weight(kg) | 17300±300 | Steering Pump | Gear Pump | ||||||||||
| Traction Force(kN) | 155±3 | System Pressure(MPa) | 15 | ||||||||||
| Breakout Force(kN) | 170±3 | Flow Rate(L/min/rpm) | 176/2200 | ||||||||||
| L×W×H(mm) | 8050×3034×3530 | Steering Angle | ±35° | ||||||||||
| Travel Speeds (km/h): | Hydraulic System | ||||||||||||
| Ⅰ | Ⅱ | Lift Cylinders-bore×Stroke(mm) | 2-180×721 | ||||||||||
| Forward | 11.5 | 36 | Tilt Cylinder-bore×Stroke(mm) | 1-200×563 | |||||||||
| Reverse | 16 | Model of Implement Pump | Gear Pump | ||||||||||
| Engine | WD10G220E21 DF CUMMINS 6CTAA8.3-C215 | Flow Rate(L/min/rpm) | 220/2200 | ||||||||||
| Rated Power(kW·hp/rpm) | 162·(220)/2200160·(215)/2200 | System Pressure(MPa) | 16 | ||||||||||
| Peak Torque(Nm/rpm) | 860/1400-1600908/1500 | Pilot Control System Pressure(MPa) | 2.5 | ||||||||||
| Starting Voltage(V) | 24 | Hydraulic Cycle Time, Rated Load in Bucket(In second): | |||||||||||
| Drive Train | Raise(Loaded) | Dump | Lower(Empty) | Total | |||||||||
| Torque Converter | Single-stage, Duo-turbine, 4-element | 6 | 1 | 4 | 11 | ||||||||
| Torque Ratio | 4 | Electrical System | |||||||||||
| Transmission | Planetary Powershift Transmission | System Voltage(V) | 24 | ||||||||||
| Gear | 2F/1R | Battery (2 in series)(Ah) | 2-120 | ||||||||||
| Pressure of Transmission(MPa) | 1.2~1.5 | Lamp Voltage(V) | 24 | ||||||||||
| Main Reducer | Spiral Bevel, 1-stage Reduction | Service Refill Capacity | |||||||||||
| Final Reducer | Planetary Reduction | Fuel Tank(L) | 285 | ||||||||||
| Tire | 23.5-25 L-3 16PR TT | Hydraulic Tank(L) | 270 | ||||||||||
| Brake System | Crankshaft(L) | 20 | |||||||||||
| Service Brake | Duo Circuit Caliper,Dry Brake | Transmission(L) | 45 | ||||||||||
| Setting Pressure (MPa) | 0.70-0.78 | Front Axle(L) /Rear Axle(L) | 25/25 | ||||||||||
| Parking Brake | Air Actuated Caliper Brake | Air Conditioning System | |||||||||||
| Emergency Brake | Air Actuated Caliper Brake | Heating Capacity(W) | 5800 (±10%) | ||||||||||
| Cooling Capacity(W) | |||||||||||||
All Original Parts are Available !!!
Sales Service
u Being available online 24 hours a day.
u Responding to your e-mails at the first time.
u Providing the best choice according to the customer’s needs.
u Giving reception and organize visit of the factory, meeting, technical communication for the customers.
After-sales Service
u Warranty: Silkway grants our clients a twelve-month-period or 2000-hours warranty for any machine purchased from us. During the warranty period, the defective parts will be repaired or replaced free of charge. But it does not cover all those parts damaged due to interventions for presumed problems or non conforming verification.
u Installation&Maintenance: Silkway has the ability to provide you with overall installation of complicated machinery and equipment, such as, crawler crane, tower crane, construction hoist, etc. Helping you to carry out the normal operation of the machines immediately.
01 WHAT ARE OUR ADVANTAGES COMPARED WITH ?
u Competitive Price - As a professional construction machinery exporter, we have abundant resources for pre-sale, sale and sale service. We work as the leading dealers of various leading China construction machinery manufacturers/factories, and are treated with best dealership price every year. From numerous comparison and feedbacks from clients, our price is more competitive than manufacturer /factories.
u Quick Response- Our team is consisted of diligent and enterprising people, working to respond client inquiries and questions all the time. Most problem can be solved within 12 hours.
02 WHICH TERMS OF PAYMENT CAN WE ACCEPT ?
u On T/T term, 30% down payment should be paid in advance, and 70% balance should be paid within 5 days before departure goods from factory.
u On L/C term, a 100% irrevocable L/C at sight by our acceptable bank.
03 HOW LONG WILL OUR PRICE BE VALID ?
We are a tender and friendly supplier, never greedy on windfall profit. Basically, our price remain s stable through the year. We only adjust our price based on two situations:
u The rate of USD /RMB varies significantly according to the international currency exchange rates.
u Manufacturers/factories adjusted to the machine price, because of the increasing of labor cost and raw material cost.
04 WHAT LOGISTICS WAYS WE CAN WORK FOR SHIPMENT?
We can ship construction machinery by various transportation tools.
u For 90% of our shipment, we will go by sea, for other machinery, like truck crane, big bulldozer and road roller, either by RO/RO and Bulk shipment.
u For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan, etc., we can ship construction machinery by road or railway.
u For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
05 HOW LONG IS OUR GUARANTEE TIME?
u 2000 working hours or one year from the date of B/L, which comes first.
u Engineers available to service machinery overseas.
SILKWAY will empower your will of project
Silkway is very famous construction machinery exporter in China and have exported products to more than 60 countries. Our main products are as follows: XCMG wheel loader, road roller, motor grader, excavator, truck crane and SHANTUI bulldozer etc. We always guarantee official products, quick after-sale service, and the most competitive price.
