Piece-structure Mast Section Tower Crane TC4010

Name: Piece-structure Mast Section Tower Crane TC4010
Brand: Silkway
SKU: 140803908
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Rated Loading Capacity:

Rated Lifting Moment:

QTZ40B

Xuzhou Silkway Machinery & Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Rated Loading Capacity 4t

Rated Lifting Moment QTZ40B

Max. Lifting Load 1t

Max. Lifting Height 140m

Place of Origin Jiangsu, China

Brand Name Silkway

Model Number TC4010

Specifications

Max.load:4t,
Boom length:40m,
Jib end loading:1t,
Max.height:140m,
Mast section:1.6*1.6*3.0m

Piece-structure mast section, Convenient for container shipment.

High quality and competitive price, high performance.

Specialist for exporting tower crane

With Hydraulic Self-raising Mechanism

With Famous Jiangte Motors

With Various Safety Devices

Model	TC4010 (QTZ40B)
Version	Fixed type
Free height	32 meters
Max height	140 meters
Max radius	40 meters
Jib end load	1ton at 40 meters
Max load	4tons at 12.9 meters
Hoisting mechanism ↑↓	JT1
Drum capacity	200 meters
Lifting speed	3.32m/min~60.97m/min
Slewing mechanism ()	HZ-40
Slewing speed	0.7r/min
Trolley mechanism ←→	BF-40
Trolley speed	28m/min
Power line voltage	380V/50Hz
Color	Yellow
Counter weight	Steel-structured frame(without concrete)
Mast section	1.6×1.6×3m
Mast section and Mast section connection	By screw
Foundation bolt	Included (8sets)
Cabin (with air condition)	Included
Telescoping cage	Included
Pump and cylinder	Included
Main cable	Included
Basic mast	Included
