Product Name: Aluminum alloy A-shape Lattice Gin Pole
Use and Characteristics:
During used for transmission and distribution,telecommunication engineering tower erection.
The main material adopts right angle aluminum titanium alloy section, rivet joint makes, portable and durable.
Quality Control
We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.
Our Values
1,Take First-Class Quality as Target and First-class Service.
2,As Responsibility, To Succeed By Scientific Management.
3,Customer in Heart, Quality in Hand, Technology in the Lead.
Technical Data for Aluminum alloy A-shape Lattice Gin Pole
| Product NO. | Type NO. | Length(m) | Cross section(mm) | carrying capacity(KN) | weight(kg) |
| 80486 | LBR-9 | 9 |
250*250 |
50 |
100 |
| 80487 | LBR-10 | 10 |
250*250 |
50 |
110 |
| 80488 | LBR-10 | 10 |
300*300 |
65 |
120 |
| 80489 | LBR-11 | 11 |
300*300 |
65 |
130 |
| 80490 | LBR-12 | 12 |
300*300 |
65 |
140 |
| 80491 | LBR-13 | 13 |
300*300 |
50 |
145 |
| 80492 | LBR-9 | 9 | 350*350 | 60 | 120 |
| 80493 | LBR-10 | 10 | 350*350 | 60 | 130 |
| 80494 | LBR-11 | 11 | 350*350 | 50 | 140 |
| 80495 | LBR-13 | 13 | 350*350 | 50 | 150 |
| 80496 | LBR-13 | 13 | 400*400 | 70 | 240 |
| 80497 | LBR-17 | 17 | 400*400 | 50 | 290 |
| 80498 | LBR-15 | 15 | 500*500 | 70 | 300 |
| 80499 | LBR-17 | 17 | 500*500 | 60 | 330 |
| 80450 | LBR-21 | 21 | 600*600 | 100 | 380 |
| 80451 | LBR-27 | 27 | 600*600 | 80 | 400 |
