Specifications
Hand Anchor Winch1)small in size, light in weight
2)high quality, top in China
Hand Anchor Winch
Use and Characteristic
1) Capacity: 0.8T x 20M, 1.6T x 20M, 3.2T x 20M, 5.4T x 20M.
2) All hoists are supplied complete with 20 meter wire rope and an extendable operating lever.
3) Wire rope is tapered one end and fitted with a hook and safety catch at the other end.
3) The hoist has low maintenance requirements and is easy service.
4) Overload protection ensures high personal safety when in operation.
5) Specially built-in shear pins can be replaced without removing the load.
Quality Control
We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.
Our Values
1,Take First-Class Quality as Target and First-class Service.
2,As Responsibility, To Succeed By Scientific Management.
3,Customer in Heart, Quality in Hand, Technology in the Lead.
Technical Data for Hand Anchor Winch
Model item |
VIT-800 |
VIT-1600 |
VIT-3200 |
VIT5400 |
Rated forward hand power(N) |
341 |
438 |
438 |
745 |
Rated capacity(KG) |
800 |
1600 |
3200 |
5400 |
Rated forward travel(MM) |
≥52 |
≥55 |
≥28 |
≥30 |
Rope diameter(MM) |
8.3 |
11 |
16 |
20 |
Wire rope safty factor load capacity(TIMES) |
5 |
5 |
5 |
5 |
Max travelling load(KG) |
1200 |
2400 |
4000 |
8000 |
Net weight(KG) |
6.4 |
12 |
28 |
56 |
Max outer size(MM) A |
426 |
545 |
660 |
930 |
B |
238 |
284 |
325 |
480 |
C |
64 |
97 |
116 |
152 |
L1(CM) |
|
80 |
80 |
68 |
L2(CM) |
80 |
120 |
120 |
112 |
Packing (L*W*H)(CM) |
43*6.4*24 |
54.5*9.7*29 |
66*12*35 |
110*110*73 |
