3.5 Ton High Quality Hydraulic Power Puller

Specifications

3.5 Ton High Quality Hydraulic Power Puller
1)attractive appearance
2)Low noise
3)Good balance
4)safe





3.5 Ton High Quality Hydraulic Power Puller



Characteristic

1.It is applied to traction in the process of paying off the wire,earth wire,OPGW and ADSS.

2.Closed Hydraulic back oil circuit, bidirectional  variable plunger pump ,you can change the traction in any case.

3.Maximum traction force can be preset, automatic overload protection.

4.Pressure loss automatic braking device is used to ensure the safety of system operation

when loss of pressure in case of the engine suddenly stops or other causes.

5.Hydraulic traction rope clamping device, automatic rope ,convenient to loading and unloading.

6. Trailer type structure,rigid scaffold,attractive appearance.



Quality Control



We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.



Our Values



1:Take First-Class Quality as Target and First-class Service.

2:As Responsibility, To Succeed By Scientific Management.

3:Customer in Heart, Quality in Hand, Technology in the Lead.



Technical Data of 3.5 Ton High Quality Hydraulic Power Puller

Product Number	80023	80024	80025
Model Type	SA-YQ-35B	SA-YQ-55B	SA-YQ-80B
Rated Pulling Force(KN)	35	55	80
Continual Pulling Force(KN)	30	50	60
Max Pulling Speed(m/min)	80	85	95
Bottom Dia of Drum(mm)	Φ320*2	Φ460*2	Φ540*2
Number of Grooves	7	7	8
Max Dia of Applicable Wire Rope(mm)	Φ15	Φ17	Φ21
Max Connector(mm)	Φ40	Φ52	Φ65
Dimension(mm)	3300*1650*2200	3600*1700*2200	3500*2250*2100
Weight(KG)	1650	2200	4000
