SA-YZ2*40A Hydraulic Tensioner For Wire And Conductor Stringing

Application

Tension machine is used in power transmission and distribution engineering, telephone construction tower erection, traction cable, line, hoisting tools or heavy objects , the electric winch  is driven by a belt, effectively prevent the damage of overload, there are pros and cons and the speed of file, anti reverse gear moment to ensure the safety of construction.

Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical  shape and coming with steel rope.

Essential parameter:

Maximum Tension(KN): 2×40 or 1×80

Continuous Tension(KN): 2×35 or 1×70

Maximum speed(km/h): 5

Bullwheel bottom of groove diameter(mm): φ1500

Number of grooves: 2×5

Maximum pullback(KN): 2×40 or 1×80

Maximum speedback(km/h): 2×1.2

Maximum suitable conductor diameter(mm): φ40

Engine power/speed(km/rpm): 51/2500

Dimensions(mm): 4500×2200×2800

Weight(kg): 4850

Uses:

Used to string various conducts and earthwires. It also on pull one or one pull four using.

Features:

1.Bullwheel with wearproof MC nylon lining segments.

2. Infinitely variable tension control and constant tension conductor stringing .

3. Spring applied hydraulic released brake acts automatically in case of  hydraulic failure to ensure safety .

4. Attached two sets of hydraulic power output interface to connect hydraulic conductor  reel  stand .

Main component:

1. Engine : Deutz air-cooled diesel engine.

2. Main pump/motor: Rexroth(BOSCH)

3. Reducer : RR(Italian)

4. Radiator :AKG

5. Hydraulic instrument :WIKA

6. Hydraulic valve:  Rexroth(BOSCH)

7. It can choose the Chinese air-cooled engine. The model is SA-YZ2×40B.

8. According to needing, its can configure mobile control consoles, it easy  for one operator to control 2 machines simultaneously, which facilitates 4-conductorstringing operation using  two machine. The control consoles order number is: 07193.
