Multi Function Hydraulic Busbar Processor
Use and Characteristic
Multi Function Hydraulic Busbar Processor is the combination of punching,bending and cutting.
The manometer with the pressure of 1000kgs/cm makes the process under control,prevent the machine from overloading.
The hand switch can be adjusted easily to control the depth and the width of the sheet
Four direction valve makes the process of punching,bending and cutting go accurately
Reliable and stable foot-type switch
Quality Control
We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.
Our Values
1,Take First-Class Quality as Target and First-class Service.
2,As Responsibility, To Succeed By Scientific Management.
3,Customer in Heart, Quality in Hand, Technology in the Lead.
Technical Data Multi Function Hydraulic Busbar Processor
| Product No. | 80098 |
| Model Type | OK-501 |
| Normal Operating Pressure(Psi) | 1000 |
| Power Souce(12V) | 220V/380V 50Hz |
| Output of cutting machine(KN) | 200 |
| Cutting Range(mm) | copper and aluminum≤ 150*12 |
| Output of hole punching machine(KN) | 300 |
| Hole punching range(mm) | Φ11.5 - Φ19.5 |
| Output of bending machine(KN) | 270 |
| Flatting range(mm) | copper and aluminum≤ 125*12 |
| Bending range(mm) | copper and aluminum≤ 125*12 |
| Flatting Angle(°) | 0-135 |
| Bending Angle(°) | 0-90 |
| Weight(kg) | 188 |
