US$ 8,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
TIMAC
Model Number:
TWG-15E, TWG-20E, TWG-25E, TWG-30E, TWG-35E
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
TIMAC
Model Number
TWG-15E, TWG-20E, TWG-25E, TWG-30E, TWG-35E
Type
Powered Pallet Truck
Power Souce
Gasoline Engine
Rated Loading Capacity
1500-3500KG
Max. Lifting Height
6000MM
Min. Lifting Height
120MM
Fork Length
1100MM
Fork Width
130MM
Overall Dimensions
2890X1250X2139MM
Gasoline Forklift
LPG forklift
Characteristic:
* Streamlined exterior and high-strength frame
*Comfortable driving room and mini steering wheel
*transverse steering axle as Buffer device
*Reliable special designed instrument
*Overhead intake system,Integral hood,effectual in heat insulation and noise reduction
*Imported diesel and gasoline engines can be option to save energy and increase efficiency.
*Choose gasoline and LPG as power according to customers’demands
Specifications:
1) Rated capacity (kg): 1500,2000, 2500, 3000, 3500
2) Max lifting height (mm): 3000, 4000, 4500, 4800, 5500, 6000
3) All kinds of attachments for special function available
4)Diesel engine: Japan Isuzu ,Yanmar,Nissan or Chinese engines
Main Technical Specifications:
| Model | Unit | TWG-15E | TWG-20E | TWG-25E | TWG-30E | TWG-35E | |
| Power type | Gasoline/PLG | Gasoline/PLG | Gasoline/PLG | Gasoline/PLG | Gasoline/PLG | ||
| Rated capacity | kg | 1500 | 2000 | 2500 | 3000 | 3500 | |
| Load center | 500 | 500 | 500 | 500 | 500 | ||
| Lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | |
| Free lifting height | mm | 120 | 120 | 120 | 120 | 120 | |
| Fork size | mm | 900×/120×35 | 1100×/130×50 | 1100×130×50 | 1100×130×50 | 1100×130×50 | |
| Mast tilting angle | deg | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | |
| Overall length | mm | 2280 | 2495 | 2565 | 2725 | 2890 | |
| Overall width | mm | 1070 | 1150 | 1150 | 1225 | 1250 | |
| Mast lowered height | mm | 2082 | 2114 | 2114 | 2139 | 2139 | |
| Mast extended height | mm | 3585 | 3585 | 3585 | 3585 | 3585 | |
| Overhead guard height | mm | 2130 | 2090 | 2090 | 2140 | 2140 | |
| Min.turning radius | mm | 1955 | 2170 | 2240 | 2450 | 2650 | |
| Speed | Travel speed | km/h | 14.5 | 20 | 20 | 20 | 18 |
| Lifting height | mm/sec | 500 | 450 | 450 | 400 | 400 | |
| Max. gradeability | % | 19 | 19 | 19 | 15 | 15 | |
| Self weight | kg | 2660 | 3550 | 4000 | 4500 | 5000 | |
