Help CenterTHREE-JAW SELF-CENTERING CHUCKS
US$ 50 - 5,000
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
TIMAC
Model Number:
K11 series
Power:
Manual
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
TIMAC
Model Number
K11 series
Power
Manual
Number of Jaws
3
THREE-JAW SELF-CENTERING CHUCKS
Features:
1.Short cylindrical center mounting
2.Model K11 chucks are provided with solid jaws(which include a set of internal jaws and a set of external ones)
3.The jaws for K11A,K11C,K11D,K11E chucks are composed of reversible jaws.They can perform as either internal or external jaws through adjustment
4.The jaws for K11A and K11D,K11E chucks conform to ISO3442 standard
5.Model K11C chucks are supplied with traditional reversible jaws
6.We can provideall kinds of soft jaws
7.As requested ,we can provide chucks mounted from front.
Parameters:
| D Size | D1 | D2 | D3 | H | H1 | H2 | h | S | z-d | Nm | r/min |
| Max.input torque | Max.speed | ||||||||||
| 80 | 55 | 66 | 16 | 66 | 50 | — | 3.5 | 8 | 3-M6 | 40 | 4000 |
| 100 | 72 | 84 | 22 | 74.5 | 55 | — | 3.5 | 8 | 3-M8 | 60 | 3500 |
| 125 | 95 | 108 | 30 | 84 | 58 | — | 4 | 10 | 3-M8 | 100 | 3000 |
| 130 | 100 | 115 | 30 | 86 | 60 | — | 3.5 | 10 | 3-M8 | 100 | 3000 |
| 160 | 130 | 142 | 40 | 95 | 65 | — | 5 | 10 | 3-M8 | 160 | 2500 |
| 160A | 130 | 142 | 40 | 109 | 65 | 71 | 5 | 10 | 3-M8 | 160 | 2500 |
| 165 | 130 | 145 | 40 | 96.5 | 66.5 | — | 4.5 | 12 | 3-M8 | 160 | 2500 |
| 190 | 155 | 172 | 55 | 105 | 75 | — | 5 | 12 | 3-M10 | 250 | 2000 |
| 200 | 165 | 180 | 65 | 109 | 75 | — | 5 | 12 | 3-M10 | 250 | 2000 |
| 200C | 165 | 180 | 65 | 122 | 75 | 78 | 5 | 12 | 3-M10 | 250 | 2000 |
| 200A | 165 | 180 | 65 | 122 | 75 | 80 | 5 | 12 | 3-M10 | 250 | 2000 |
| 240 | 195 | 215 | 70 | 120 | 80 | — | 8 | 12 | 3-M12 | 320 | 1600 |
| 240C | 195 | 215 | 70 | 130 | 80 | 84 | 8 | 12 | 3-M12 | 320 | 1600 |
| 250 | 206 | 226 | 80 | 120 | 80 | — | 5 | 12 | 3-M12 | 320 | 1600 |
| 250C | 206 | 226 | 80 | 130 | 80 | 84 | 5 | 12 | 3-M12 | 320 | 1600 |
| 250A | 206 | 226 | 80 | 136 | 80 | 86 | 5 | 12 | 3-M12 | 320 | 1600 |
| 315 | 260 | 285 | 100 | 147 | 90 | — | 6 | 14 | 3-M16 | 400 | 1200 |
| 315A | 260 | 285 | 100 | 153 | 90 | 95 | 6 | 14 | 3-M16 | 400 | 1200 |
| 320 | 270 | 290 | 100 | 152.5 | 95 | — | 11 | 13 | 3-M16 | 400 | 1200 |
| 320C | 270 | 290 | 100 | 153.5 | 95 | 101.5 | 11 | 13 | 3-M16 | 400 | 1200 |
| 325 | 272 | 296 | 100 | 153.5 | 96 | — | 12 | 13 | 3-M16 | 400 | 1200 |
| 325C | 272 | 296 | 100 | 154.5 | 96 | 102.5 | 12 | 13 | 3-M16 | 400 | 1200 |
| 325A | 272 | 296 | 100 | 169.5 | 96 | 105.5 | 12 | 13 | 3-M16 | 400 | 1200 |
| 380 | 325 | 350 | 135 | 155.7 | 98 | — | 6 | 14 | 3-M16 | 500 | 1000 |
| 380C | 325 | 350 | 135 | 156.5 | 98 | 104.5 | 6 | 14 | 3-M16 | 500 | 1000 |
| 380A | 325 | 350 | 135 | 171.5 | 98 | 107.5 | 6 | 14 | 3-M16 | 500 | 1000 |
| 400 | 340 | 368 | 138 | 158 | 100 | - | 6 | 17 | 3-M16 | 500 | 1000 |
| 400D | 340 | 368 | 138 | 172 | 100 | 108 | 6 | 17 | 3-M16 | 500 | 1000 |
| 500 | 440 | 465 | 210 | 184 | 115 | - | 6 | 17 | 6-M16 | 630 | 800 |
| 500D | 440 | 465 | 210 | 202 | 115 | 126 | 6 | 17 | 6-M16 | 630 | 800 |
| 500A | 440 | 465 | 210 | 202 | 115 | 126 | 6 | 17 | 6-M16 | 630 | 800 |
| 630 | 560 | 595 | 270 | 214 | 133.5 | - | 7 | 19 | 6-M16 | 800 | 600 |
| 630D | 560 | 595 | 270 | 218 | 133.5 | 142 | 7 | 19 | 6-M16 | 800 | 600 |
| 630E | 560 | 595 | 270 | 220.5 | 133.5 | 142 | 7 | 19 | 6-M16 | 800 | 600 |
| 800D | 710 | 760 | 385 | 250 | 161 | 170 | 8.5 | 21 | 6-M20 | 1000 | 500 |
| 800E | 710 | 760 | 385 | 250 | 161 | 170 | 8.5 | 21 | 6-M20 | 1000 | 500 |
| 1000E | 905 | 950 | 460 | 310 | 198 | 216 | 9 | 24 | 6-M24 | 1200 | 400 |
| 1250E | 1060 | 1150 | 550 | 341 | 228 | 237 | 11 | 24 | 6-M30 | 1300 | 320 |
