Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > CNC Surface Grinding Machine

CNC Surface Grinding Machine

Name: CNC Surface Grinding Machine
Brand: TIMAC
SKU: 140797334
Availability: InStock

CNC Surface Grinding Machine thumbnail-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Surface Grinding Machine

CNC or Not CNC

Place of Origin Henan, China

Brand Name TIMAC

Model Number SG-2050CNC, SG-2550CNC

Certification ISO, CE, TUV

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.CNC surface grinding machine;
2.Siemens Sinumerik 808D CNC control;
3.Working area of 250x500mm;
4.Saddle-move arrangement

CNC Hydraulic Saddle Moving Type Surface Grinding Machine

CNC controller: Siemens SINUMERIK 808D;

CNC2 series : hydraulic for longitudinal direction, CNC for cross and vertical direction;

CNC3 series: CNC for longitudinal, cross and vertical direction.

***Standard Accessories:
SIEMENS SINUMERIK 808D CNC system;
Coolant tank, Electronic magnetic chuck, Wheel balancing arbor, Wheel flange,
Wheel extractor, Leveling wedge and bolt, Tool box & tools, Standard grinding wheel,
Wheel dresser stand, Diamond pen, Built in electro magnetic chuck controller, etc.

Specification		Unit	SG-2050CNC2	SG-2550CNC2
			SG-2050CNC3	SG-2550CNC3
Table size(WxL)		mm	200x460	254x508
Max. longitudinal travel		mm	510	570
Max. cross travel		mm	238	275
Max.distance from spindle center to table surface		mm	450	450
Electro magnetic chuck size		mm	200x460	250x500
Table longitudinal movement	Speed	m/min	5~25(CNC2 model); 0.02~15(CNC3 model)
	Feed of electro hand wheel	mm/div.	0.005 (CNC3 model)
Table transverse movement	Auto feed	mm/stroke	0.1~8
	Rapid speed	mm/min	0.05~1
	Feed of handwheel	mm/div.	0.005
Wheelhead vertical movement	Auto feed	mm/stroke	0.005~0.05
	Rapid speed	mm/min	0.05~1
	Feed of handwheel	mm/div.	0.005
Grinding wheel	Speed	rpm	2850(50Hz), 3450(60Hz)
	Size(ODxWxID)	mm	200x20x31.75
Spindle motor		kw	1.5	2.2
Hydraulic motor		kw	0.75 (CNC2 model)
Cooling pump motor		kw	0.04
Parellism of working surface to mounting base		mm	300:0.005
Roughness of working surface		μm	Ra≤0.63
Max.loading capacity of table(include magnetic chuck)		kg	120	180
Height of machine		mm	1675
Floor space(LxW)		mm	2050x1400	2300x1600
Gross weight		kg	1600	1800
Package dimensions(LxWxH)		mm	1780x1500x2155	2000x2100x2150
