VALVE GRINDER MACHINE
US$ 1,500 - 2,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Valve grinding machine
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TB8016 VERTICAL AIR-FLOATING FINE BORING MACHINEUS$ 6,750 - 7,500MOQ: 1 Set -
VERTICAL CYLINDER HONING MACHINEUS$ 2,000 - 3,000MOQ: 1 Set
-
CYLINDER BORING MACHINEUS$ 1,000 - 1,500MOQ: 10 Sets
-
CYLINDER BORING MACHINEUS$ 1,000 - 1,500MOQ: 10 Sets
-
VERTICAL CYLINDER BORING MACHINEUS$ 1,000 - 1,500MOQ: 10 Sets
Condition
New
Type
Other, Valve grinding machine
CNC or Not
Normal
Brand Name
TIMAC
Model Number
VR90
Specifications
1. Valve grinding2. Valve dia. 90mm
3. Valve stem dia. 6-16mm, 4-7mm, 12-18mm
Features:
1. This machine is special for grinding the valves in internal combustion engines (the valves in engines on automobiles and tractors), featuring small size, flexible operation and easy use.
2. The parts are ground with high surface finish and accuracy.
| Specification | Unit | VR90 |
| Max. dia. of valves to be ground | mm | 90 |
| Dia. of valve stems to be gripped (standard accessories) | mm | 6-16 |
| Dia. of valve stems to be gripped (special accessories) | mm | 4-7 |
| Dia. of valve stems to be gripped (special accessories) | mm | 12-18 |
| Angles of valves to be ground | (°) | 25-60 |
| Longitudinal movement of geared head | mm | 120 |
| Transverse movement of grinding wheel head | mm | 95 |
| Max. cutting depth of ground valve | mm | 0.025 |
| Grinding wheel spindle speed | rpm | 4500 |
| Geared head spindle speed | rpm | 125 |
| Motor output for grinding wheel head | kw | 0.37 |
| Motor output for geared head | kw | 0.09 |
| Weight | kg | 120 |
| Overall dimensions (LXWXH) | cm | 68x60x60 |
