VERTICAL DRILLING MACHINE
Features:
• Equipped with a large tee slotted table and power feed, this machine is robust
enough for milling, drilling and boring. And the head is adjustable on the
column. Head also swivels left and right. These features expands the capacity of
this machine. You can also change speeds quickly and easily.
• Digital readout for display of speed and cutting depth (D-40A & D-50A)
• Rigid cast iron construction
• Halogen work light as standard
• Tables rotates 180 and swivels 45°
• Adjustable depth stop
• Thick-walled column
• Extremely easy tool change
• Coolant system
• CE compliant
Standard accessories:
Key type drill chuck; Connecting bar for drill chuck; Shaft sleeve for taper shank tool;
Wedge for taper shank tool; Double open end spanner.
Specification |
D-30A |
D-32A |
D-35A |
Max. drilling dia.(mm) |
Φ30 |
Φ32 |
Φ35 |
Max. taping dia.(mm) |
M20 |
M22 |
M22 |
Spindle travel (mm) |
110 |
160 |
160 |
Throat depth (mm) |
260 |
320 |
320 |
Distance spindle/table (mm) |
685 |
630 |
585 |
Distance spindle/base (mm) |
1165 |
1185 |
1140 |
Drilling table swivel |
±45° |
±45° |
±45° |
Spindle taper bore (MT) |
3 |
4 |
4 |
Spindle speed steps |
12 |
12 |
12 |
Spindle speed range (r.p.m) |
125-3030 |
125-3030 |
125-3030 |
Spindle feed steps |
3 |
3 |
3 |
Spindle feed range (mm/r) |
0.1-0.3 |
0.1-0.3 |
0.1-0.3 |
Worktable size (cm) |
42 x 35 |
50 x 42 |
50 x 42 |
Column diameter(mm) |
Φ110 |
Φ120 |
Φ120 |
Power of motor (kw) |
1.1 |
1/1.2 |
1.2 |
Packing dimension (cm) |
87x55x222 |
96x58x208 |
94x57x212 |
N.W/G.W (kg) |
340/380 |
500/555 |
430/475 |
