M250 Universal Turret milling machine / Vertical turret milling machine
- 50 Set / Sets per Month
- China Port
- T/T
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial CNC Milling Machine, production, Machine Center for steel, stainless
Product Details
Condition: | New | Brand Name: | TIMAC | Model Number: | M250 |
Type: | Vertical | CNC or Not: | Normal | Voltage: | As customer request |
Power(W): | 3.75kw | Dimension(L*W*H): | 1516 x 1550 x 2080mm | Weight: | 1590 |
Certification: | CE norms; ISO9001 | Warranty: | 1 year after delivery |
Product Description
Specifications
Universal Turret milling machine/Vertica turretl milling machine1.Table size:254x1370mm
2.High Precision Taiwan Made
Turret milling machine / Universal milling machine / Vertical milling machine
Technical Specification:
Model | Unit | M230A | M230B | M250 | M250A | M250B | M250U | M250C | M250D | M300 | M300A | M330 | M330A | |
Table size | mm | 230x1067 | 254x1270 | 250x1270 | 254x1270 | 305x1370 | 330x1370 | |||||||
230x1246 | 254x1370 | 254x1370 | 305x1500 | 330x1500 | ||||||||||
Longitudianl travel | mm | 650 / 840 | 850 / 950 | 770 | 850 / 950 | 870 / 1000 | 840 / 1000 | |||||||
Cross travel | mm | 305 | 420 | 400 | 420 | 380 | 368 | |||||||
Vertical travel | mm | 400 | 420 | 400 | 420 | 430 | 450 | |||||||
T-slot No. and size | mm | 3 x 16 | ||||||||||||
Ram travel | mm | 312 | 470 | 500 | ||||||||||
Distance from spindle to table | mm | 0-415 | 0-405 | 0-350 | 0-450 | |||||||||
Spindle hole taper | Standard: R8 Optional : ISO30/ISO40 | Standard: ISO40 | ||||||||||||
Spindle travel | mm | 127 mm | ||||||||||||
Spindle speed | r.p.m | Standard: step 16 speed 50HZ: 65-4500 60HZ: 80-5440 | ||||||||||||
Optional: Variable speed 65-4500 | Optional: Variable speed: 65-3750 | |||||||||||||
Auto. quill feed | mm/r | Three steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15(0.006″) | Three Steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15 (0.006″) | |||||||||||
Spindle Motor | kw/HP | 2.25kw / 3HP | 3.75kw / 5HP | 3.75kw / 5HP | ||||||||||
Head Swivel | 90° | |||||||||||||
Head Tilting | 45° | Fix | 45° | Fix | 45° | Fix | ||||||||
Dimension of package | One | mm | 1400x1476x2030 | 1516x1550x2080 | 1566x1650x2080 | 1800x2016x2180 | ||||||||
Two | mm | 1450x1570x2080 | 1650x1790x2170 | 1720x1800x2175 | 1800x2200x2180 | |||||||||
Three | mm | 1450x2180x2080 | 1650x2285x2235 | - | - | |||||||||
Gross Weight | kg | 1100 | 1160 | 1550 | 1380 | 1420 | 1650 | 1590 | 1590 | 1700 | 1750 | 2300 | 2350 |
Features:
M230A:
*Double 55°dovetail guide way is adopted on Both Y and Z axis;
*Adopted strengthen rib on both sides of the column;
*The work table surface and 3 axis guide way are hardened and precision ground.
M230B:
*Double 55°dovetail guide way is adopted on Z axis, and rectangular guide way on Y axis;
*Adopted strengthen rib on both sides of the column;
*The work table surface and 3 axis guide way are hardened and precision ground
M250A:
*Double 55°dovetail guide way is adopted on Both Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
*The work table surface and 3 axis guide way are hardened and precision ground.
M250B:
*Double 55°dovetail guide way is adopted on Z axis, and rectangular guide way on Y axis;
*The guide way on saddle is lined with TF wearable material;
*The work table surface and 3 axis guide way are hardened and precision ground.
M250:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material.
M250C:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*Fixed structure is used to connect the mill head without adapter;
M250D:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm.
M250U:
*Rectangular guide ways on Y and Z axis;
*X, Y axis adopt auto feed gear box; Feed motor: 250w; Feed rate: 15, 23, 33, 48, 78, 114, 166, 257;
*The work table surface and 3 axis guide way are hardened and precision ground.
M300:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
M300A:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor;
*Fixed structure is used to connect the mill head without adapter;
M330:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
* Super saddle structure.
M330A:
*Rectangular guide ways on Y and Z axis;
*The guide way on saddle is lined with TF wearable material;
* 5HP milling head motor and quill diameter is 100mm;
*The work table surface and 3 axis guide way are hardened and precision ground;
*Z axis adopts high speed lifting motor.
* Super saddle structure;
*Fixed structure is used to connect the mill head without adapter.
***Standard accessories:
Draw bar, Electric box, Working light, Hand oil pump, Tool & tool box
***Optional accessories:
Digital readout system(DRO), Machine vise, Power feed unit, Gear box power feed, Clamping kits, ISO40 collet chuck, R8 collet chuck, Oil collecting plate, Plastic splash guard, Cooling system
Milling Head made from Tanwan
(Alternatives: Step Pulley Head; Variable Speed Head; Inverter Head)
Milling Machine Assembly
Finished Milling Machine View
Production Capacity for 150 Sets Per Month
For more machine's information, please vistit our website: ;
or email to Peter Wong: sale03 at timeway
Hope you like our machines and professional service !!!
