Horizontal Boring Milling Machine/Large Sized Boring Milling Machine

Name: Horizontal Boring Milling Machine/Large Sized Boring Milling Machine
Brand: TIMAC
SKU: 140796712
Availability: InStock

Zhengzhou Timeway Machine Tool Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

TIMAC

Payment & Shipping

Payment Methods:

Port of Shipment:

China port.

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name TIMAC

Model Number TXS-100B/2

Type Horizontal

CNC or Not Normal

Voltage As request

Power(W) 7.5kw

Dimension(L*W*H) 4910x2870x2750mm

Weight 14500kg

Certification CE,ISO

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Horizontal boring milling machine;
2. Boring spindle dia. 110mm;
3. Table travel 900x1250x1400mm.

*The machine is suitable for drilling, reaming, boring holes, milling surface, and turning threads, etc.

*The facing head slide block make radial feed, can boring the large sized holes, turning excircle and grooving, etc.

Specification		TXS-100B/2
Boring spindle diameter		110mm
Spindle taper		Morse No.6 (optional ISO7:24 No.5)
Max. spindle torque		1225N.m
Max. facing head torque		1960N.m
Max. spindle thrust		12250N
Max. traverse of boring spindle		600mm
Number of spindle speed		22
Range of spindle speed		8-1000r/min
Travel of facing slide		180mm
Table working surface		1100×960mm
Max. permissible load on table		2500kg
Distance between spindle axis and table surface	Max.	900mm
	Min.	0
Table travel	Y	900mm
	X	1250mm
	Z	1400mm
Transverse rapid for spindle, headstock, worktable		2500mm/min
Range of spindle, headstock and table feeds per spindle revolution		0.04-6/0.01-1.88mm/r
Power of main drive motor		7.5kW
Overall dimensions(L×W×H)		4910x2870x2750mm
Weight of machine		14500kg
