Solder Termina Micro Push Button Switch KW-1038-M10

solder termina micro push button switch KW-1038-M10

micro push button switch
A.Without Lever
B.SPDT, SPST
C.Kw-1038-M10
D.Certification:CE,CQC

• The Main Thchnology Performane

  Item		Value
  Operating speed		0.1mm-1m/s(related with actuator)
  Operating frequency		Mechanical 60 cycles/min; Electrical 25cycles/min
  Insulation resistance		≥100 MΩ(500Vdc)
  Contact resistancy		≤30 mΩ(initial value)
  Test voltage	Between terminals of the same polarity	AC 1000V,50/60Hz,1min
  	Between current-carrying mental parts and ground, and between each terminal and non-current-carrying metal parts	AC 3750V,50/60Hz,1min
  Vibration resistance		10~55Hz,1.5mm Double amplitude
  Shock resistance		Malfunction:300/s² (approx.30)max
  life		Mechanical≥1,000,000cycles Electrical≥100,000cycles
  Safety approvals		CE,UL,CQC



1.Operation speed: 0.1mm-1m/s

2.Operation frequency: Mechanical 240 times/min

                                         Electrical  20 times/min

3.Contact resistance: 25m ohm initial value

4.Insulation resistance: more than 100M ohm

5.Withstand voltage: Non-connection wire 1500V AC

                                    Every terminal 2000V AC

6.Vibration: Miss-operation 10-55Hz Amplitude 1.5mm

7.Impact: Durable 1000m/s

       Miss-operation 300m/s

8.Life: Electrical more than 100,000 times

Mechanical more than 1,000,000 times

9.Ambient temp.: -20~+80 degree centigrade

10.Humidity: less than 85%

• Application

They are widely used in household appliances, electric force, telecommunications, machine tool, vessel, textile, printing, Mining machine, Mustic Instrument, etc.

• Others

            Please kindly inform us which items you are interested, and the best price will be provided you upon receipt of your

            new inquiry ASAP.

            Any questions about more items, please feel free to contact us.

            We are sincerely looking forward to establish cooperative relationship with you.

            Free sample is available !

            If you need any parts, please kindly send us your drawings or sample for quotation.

• PRODUCT SHOW

• CERTIFICATIONS

• PRODUCING DEPARTMENTS

           Daier Electronics Co.,ltd is a professional manufacturer of electromechanical switches in Yueqing,China. Our factory covers an area of over 5,000 square meters, having a total staff of over 200 members. We are engaged in producing 9 categories and about 4,000 models of BNC connectors, push button switches, rocker switches, micro switches, touch switches, lift switches, refrigerator door switches, miniature toggle switches, indicators, alligators, fuse holders, signal lamps and etc. With a principle of being creative, advancedand honest, we are always improving our products and services to better satisfy you customers.
