20ft 40ft Container Loading Side Loader & Self Loader
- 200 Unit / Units per Month
- MAIN port of China
- T/T Credit Card
- windturbine blade lifter trailer
- Modular Trailer
- Nozzle 0433171832,DLLA140P1340 Fuel Injector Nozzle for Construction Machinery
- Three-axle stake semi trailer/stake semi trailer/storage/stake truck/stake high bed cattle semi trailer/ semi trailer
- Three-axle side wall semi trailer/Semi trailer/Cargo Semi trailer/Semi trailer
- Mini tractor tipping trailer
Product Details
Place of Origin: | Shandong, China |
Product Description
Lifting capacity of the cranes
16 ton or 36 ton
Semi-trailer:
Straight or Gooseneck
20´ and 40´´
3 axles
Single or double tire
Adopting imported electromagnetic valve
Two speed operation
Double pumps and dual circuit hydraulic system
Adopting intelligent safety protection system
The semi-trailer is used for lifting and carrying two 20ft containers or one 40ft container in port,
Station and freight yard, the trailer’s hydraulic system power is from PTO in tractor truck, it can be operated both wireless remote control and manual operation.
The semitrailer is used for lifting and carrying two 20ft containers or one 40ft container in port, station and freight yard, the trailer’s hydraulic system power is from PTO in tractor truck, it can be operated both wireless remote control and manual operation. Dimensions and lifting capacities are made under request.
item | unit | details |
length | mm | 13900 |
width | mm | 2500 |
height | mm | 3990 |
max lifting capacity | Kg | 36000 |
working pressure | MPa | 25 |
crane weight | Kg | 7000 |
Dead weight | kg | 14510 |
container size | Feet | 20,40 |
Axle | PCS | 3×13T FUWA |
Tyre | PCS | 12* 11.00R20 |
Rim | PCS | 12* 8.00×20 |
Landing gear | PAIR | 1*JOST C200 |
Kingpin 3.5 | PCS | 1*JOST 90# |
Container Twist lock | PCS | 12 |
Leaf spring | PCS | 16 Thickness*90Width *8 Pieces |
Frame |
| Q345 |
Main beams | 2 | I BEAM 500x140,Top flange plate14,bottom flange plate 14, web plate 8,Q345 steel plate |
PLC |
| Both English and Chinese |
Electric System |
| 24v,7- core socket |
