NJD Series of Electric Loading Torque Wrench CalibratorNJD Series of Electric Loading Torque Wrench Calibrator
NJD series of electric loading torque wrench calibrator is made up of control meter box, torque transducer, loading platform, driving motor etc..
The self-combination of the control meter box and the torque transducer, which compose the precise control and display to the torque tools checking, can easily be operated beyond the loading platform by the customers. The auto continuous load and manual load of the torque tools are made up of control meter box, hand control box and driving motor.
The operation buttons and display screen adopt the advanced touch screen technology, and the manual load also uses the advanced electronic handwheel.
The calibrator operates easy and convenient, it has the following functions: display clearly, automatically input testing data, intelligent query, high precision (+/-0.3%), sampling quickly (50k/s), labor saveing etc..
Therefore, it is the ideal testing equipment for customers to examine various of hand tools, especially for the large and medium-sized enterprises or the measurement Institutes.
Parameter Table
Technical Parameter
Operating temperature: 20℃±5℃;
Rrelative humidity: ≤80%;
Accurate: 0.3 class;
Overload capability: 110% (F.S);
Sampling frequency: 50k/s;
Operation of the touch screen: display size: 200mm×145mm;
Three operation modes (Following, peak keeping and Max. Peak) can automatically convert.
Auto-alarming when error;
Two kinds of units of measurement: reset and zero cleaning;
Five units: N.m,N.cm,Kgf.cm,Lbf.ft,Lbf.in;
Bidirectional (left and right) rotating;
Examine and sensor data can be stored for use;
Power: 220VAC 50Hz.
