Chassis model

HOWO ZZ1317N4668W

Truck upper part form

          40DZ3+25T+40ZT1

Empty load(Kg)

Curb weight

32030

Front double shaft

13200

Rear double shaft

17230

Full load(Kg)

Max gross weight(two people included)

40800

Front double shaft

6640

Rear double shaft

33160

Overall dimension(mm)

Length

11420

Width

2500

Height

3570,3770( warning light installed)

Wheelbase(mm)

1800+4600+1350

Transmission

10 forward gear,1 reverse gear

Cab description

HW76 medium, luxurious interior trim with seats and air condition

Wheel tread(Front/Rear)(mm)

2022/2022; 2041/2041

Front/Rear hang(mm)

1500/1710

Rear distance(mm)

3150

Approach/departure angle(°)

16/13

Drive type

8×4

Tyre spec.

12.00-20

Max speed(Km/h)

90

Max grade ability(%)

30

Minimum turning diameter(mm)

27.5

Minimum ground clearance(mm)

310

Engine

Model

WD615.96E

Power(kW/r/min)

276/2200

Torque(N·m/r/min)

1350/1100-1600

Oil consumption per 100Km(L)

less than 32

Lifting system

Max lifting weight(Kg)

12500

Fully extended max lifting capacity(kg)

9000

Effective lifting length(mm)

1575~3214

Bracket arm flexible stroke(mm)

1639

Inclination angle under the lifting arm(⁰)

-10

Folding angle(⁰)

-10~93

Maximum distance from the ground of upper surface of full retracted cross arm(mm)

more than 900

Hoisting system

Max hoisting weight(Kg)

40000

Fully extended max hoisting weight(Kg)

4500

Basic arm length(mm)

6000

Total arm length(mm)

12000

Oil cylinder stretching stroke(mm)

6000

Max hoisting height(mm)

12070

Hoisting angle(°)

0~60

Rotation angle(°)

360°Continuous rotary

Winch

Qty(Piece)

2

Rated traction(kN)

250X2

Steel wire rope diameter(mm)

φ26

Steel wire rope length(m)

55X2

Minimum rope speed of steel wire rope(m/min)

5

Outrigger

Outrigger model

40ZT1

Front outrigger lateral span(mm)

6780

Rear outrigger lateral span(mm)

4625

Front and rear outrigger longitudinal span(mm)

8250

1.About the package of our trucks,usually it is nude that covered with wax.And it also can be packed as your need.

2.About the shipping,there are many ways,such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
