60m3 3 Axle Lpg Semi Low Bed Semi Trailer

Hubei Ocean Special Automobile Co., Ltd.

US$ 40,000 - 60,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

CLW

Model Number:

CLW9402GYQ

Payment & Shipping

Payment Methods:

Port of Shipment:

any port according to your requirement

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name CLW

Model Number CLW9402GYQ

60m3 3 axle lpg semi low bed semi trailer

factory direct sale,best price

1. Technical Features

Propane design pressure:1.77Mpa

Design temperature:50°C

Filling coefficient:0.42

Corrosion allowance:1mm

Isobutane design pressure:0.79Mpa

Dimethyl ether design pressure:1.19Mpa

Propylene, liquid ammonia design pressure:2.16Mpa

1, It is small occupied area and convenient to operating and maintaining.

2, It is the most convenient way for load, transportation and storage.

3, It is of high grade of safety.

4, It can help you to save a lot of transportation cost.

5, It is your first choice for liquid object and small amount product transportation.

Product	CLW9402GYQ LPG semi-trailer
Cubage(T)	Facture cub	56
Vehicle parameters	Overalldimension length/width/height (mm)	13000×2500×3990
	Gross weight (kg)	40000
	curb weight(kg)	15300
	Frontsuspension/rearsuspension (mm)	-/1450
	Approach/departure angle	-/25
	Max speed	-
Vehicle Description Section	Tank dimensions(Length×diameter): 12850×2496
Chassis	Chassis model
	Wheelbase (mm)	7160+1310+1310
	Front tread
	Rear tread	1840/1840/1840
	Tyre specification	11R22.5 12PR
	Fuel type	Diesel
Engine parameters	Engine	-
	Exhaust/ Power (ml/kw)
	Engine Manufacturer	-
