Dongfeng Kingland 8*4 LPG road tanker truck for sale

Main specifications

Product model,name

CLW5311GYQD LPG Transportation Truck

 (transportation media:LPG/propane)

Total weight(Kg)

31000

Tank capacity(m3)

34.50

Payload (Kg)

14490

Overall dimension(mm)

11700×2500×3720

Curb weight(Kg)

16315

Tank size(mm)

inner diameter×wall

 thickness×length:

2450×12×8757

Tank material

Q345R

Design pressure (Mpa)

1.61

cab seats (man)

3

Design temperature(°C)

50

Filling capacity per unit(t/m3)

0.42

Tank corrosion allowance(mm)

1

Approach/departure angle (°)

26/9

Front/rear hang(mm)

1460/2740

Number of axles

4

wheelbase(mm)

1950+4250+1300

Axle load(Kg)

6500/6500/18000( double axle)

Max speed(Km/h)

80

Configuration instructions

Single out the liquid,double side loading and discharge,Double valve boxes,

single tool box,safety valve,thermometer,pressure gauge,emergency shut-off

 valves,fire extinguisher , anti-static grounding tape.

Chassis specifications

Chassis model

DFL1311A3

Chassis category

the truck classis (class 2)

Brand name

Dongfeng

Manufacture

Dongfeng Motor company

Overall dimension(mm)

11475×2500×3690

Tires No.

12

Approach/departure angle (°)

28/12

Tire specification

11.00R20,295/80R22.5

Steel spring number

9/9/10

Front track(mm)

1940/1940

Type of fuel

Diesel

Rear track(mm)

1860/1860

Emission standard

GB3847-2005,GB17691-2005 EuroⅢ

Chassis model

Engine manufacture

Displacement(ml)

Power(Kw)

ISDe270 30

ISLe290 30

L270 30

L290 30

Dongfeng cummins engine co.,ltd

Dongfeng cummins engine co.,ltd

Dongfeng cummins engine co.,ltd

Dongfeng cummins engine co.,ltd

6700

8900

8900

8900

198

213

199

213
