Dongfeng New Dlk 6cbm Capacity of Vacuum Truck for Sale

Name: Dongfeng New Dlk 6cbm Capacity of Vacuum Truck for Sale
Brand: Dongfeng
SKU: 140783880
Availability: InStock

US$ 29,000 - 31,000 MOQ: 1 Set

Key Specifications

Transmission Type:

Manual

Condition:

New

Emission Standard:

Euro 4

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port in China

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Manual

Condition New

Emission Standard Euro 4

Fuel Type Diesel

Tank Volume 6cbm

Dimension (L x W x H) 7550*2500*3050

Place of Origin Hubei, China

Brand Name Dongfeng

Model Number CLW5161GXWD4

Horsepower 160hp

Gross Vehicle Weight 15790

Dongfeng new dlk 6cbm capacity of vacuum truck for sale

1. Technical Features

Main specifications
Product model,name			CLW5161GXWD4 Sewage suction truck
Gross weight(Kg)			15790			Driving type					4*2
Payload (Kg)			8425			Overall dimension (mm)					7550×2500×3050
Curb weight(Kg)			6990			Cab seats (man)					3
Approach/departure angle (°)			19/13			Front/rear hang(mm)					1230/2130
Axle No.			2			Wheelbase (mm)					3950
Axle load(Kg)			5990/9800			Max speed(Km/h)					100
Chassis specifications
Chassis model	DFA1160LJ10D4			Manufacture				Dongfeng Automobile Co,.Ltd
Brand name	Dongfeng			Overall dimension (mm)				7020×2380×2730
Tire specification	9.00-20			Tires No.				6
Steel spring number	8/10+7			Front track(mm)				1858
Fuel type	diesel			Rear track(mm)				1806
Emission standard	Euro 4			Gear box				6 forward and 1 rear
Cab	D530 - a row of semi flat cab, electric glass lifter, door lock control, channel type dashboard, AC is optional
Engine model	Engine manufacture						Displacement(ml)			Power(Kw)
ISD160 43	Dongfeng engine Co., Ltd						4500			118
Tank body
Tank capacity(m³)		6			Tank material				Q235 carbon steel
Main Characteristic
The truck is equipped with high-powered vacuum suction pump and high quality hydraulic system. With rear lid of the tank opened hydraulically, and double cylinders on both sides of the tank lifting up, the truck can dump the sewage directly through the rear lid out of the tank. Characterized by high vacuum, large capacity, high efficiency and good seal, the truck is widely used. Full tank pumping time: ≤ 5min; suction width: ≥ 8m.Very suitable for sucking sewer sediments, such as mud, silt, stones, bricks and other big objects.
