China CLW Low Transportation Cost 8 Tyres Container Semi-trailer Price

US$ 10,000 - 30,000 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

DOT

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification DOT

Size 7500x2500x1510

Max Payload 27750

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW9280TJZG

Specifications

China CLW low transportation cost 8tyre container semi-trailer price
1low transportation consumption
2high conveying efficienc

China CLW low transportation cost 8 tyres container semi-trailer price

Container semi-trailer truck specification:

Vehicle model	CLW9280TJZG Container semi-trailer	Batch No.	229
Manufacturer	Hubei Chengli Special automobile Co. ,Ltd(china)	Brand name	CLW
Overall dimension(mm)	7500×2500×1510	Total weight(Kg)	27750
Body internal dimension(mm)	××	Rating load(Kg)	24000
Approach/departure angle	-/26	Curb weight(Kg)	3750
Front/rear hang(mm)	-/1100	Max speed(km/h)
Axle number	2	Tyre number	8
Wheelbase	4240+1300	Tyre specification	11.00-20 12PR,11.00-20 14PR,11.00-20 16PR,11.00R20 12PR,11.00R20 14PR
Axle load	-/17990(double axles)	Front wheel distance
Leaf spring number	-/8/8	Rear wheel distance	1840/1840
Remarks	Container semitrailer tractor the saddle bearing surface-load from high to 1310mm, traction pin at the frame height 85mm;Car used to transport the 20-foot container.
Others	Protectivematerial:Q235 carbon steel. Connection: around the side and rear underrun protection are welded connection, rear protective section size (mm): 200 × 50 × 5.the rear protective ground clearance (mm): 520. ABS manufacturers:Haldex International Trading (Shanghai) Co., Ltd., ABS Model:2S/2M.
