DF 15m3 mini refrigerator freeze truck

FOB Price

USD $12,000 - $21,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port any port according to your requirement
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	CLW	Model:	CLW5061XLC3 refrigerator truck	Place of Origin:	China HuBei
Transmission Type:	Manual	Condition:	New
Emission Standard:	Euro 3	Fuel Type:	Diesel	Dimensions (L x W x H) (mm):	599520203000
Box Dimensions (L x W x H) (mm):	400018501800	Temperature Range:	-18℃-0℃	Gross Vehicle Weight:	6495

Product Description

Specifications

DF 15m3 mini refrigerator freeze truck
1Factory direct sale
2Certificate ISO9001
3loading 8t 15m3
4Temperature -18~+45

DF 15m3 mini refrigerator freeze truck

factory direct sale,best price

1. Certificate ISO9001

2. loading capacity 8T, 15m3

3.Temperature -18°C~+45°C

4. new design, super refrigeration, low temperature, less oil consumption

FEATURE&FUNCTION :

1.The refrigerator truck panels are made by advanced foam generation crafts and sandwich crafts: the panels are made by one-time hot-press process with the excellent FRP as the inner and the outer wall-plate, PU as the refrigerator material. So the refrigerator van has the characteristics of good refrigeration function, beautiful outlooks, and good strength.

2.We adopt refrigeration unit according to your temperature requirement on the box. The refrigeration unit uses the famous brand products of Carrier and Thermo King and it can adjust the temperature automatically, realizing the combination of the motive power and refrigeration. (KV300-10, KV500-10 without electric standby).

Main parameter

tem	parameter	unit
Vehicle model	CLW5061XLC3 refrigerator truck
Chassis model	EQ1060TJ20D3
GVW	Appro×6495	kg
Rated load wight	Appro×2865
Curb wight	Appro×3500
Overall dimensions	5995×2020×3000	mm
Compartment dimensions	4000×1850×1800
Wheel base	3300
F/R track base	1506/1466
Approach/departure angle	19/10	°
Exhaust/kw	2659/66	ml/kw
Max speed	90	km/h
Tire specification	7.00-16,6.50-16	Engine type	YC4F90-30
Traction system	4×2	Number of tires	6
Number of axles	2	Electric system	24v
Operation control system	Electrically hydraulic control	Allowable passengers in cab	2,3
Engine	Guangxi Yuchai ,diesel engine Co.,Ltd.
Function	Flat van, maintenance-free maintenance Multi-zone temperature: Xiang Ti free to the installation of side door, every folder different temperature. Car can configure: goods such as fixtures, goods suspension, the car rack, curtain, such as thermal insulation. Car back door hardware are stainless steel products, luxurious appearance
Production cycle	About 18 workdays
