Specifications
DF 40m3 refrigerator freeze truck for sale1Factory direct sale
2Certificate ISO9001
3loading 20t 40m3
4Temperature -18~+45
DF 40m3 refrigerator freeze truck for sale
factory direct sale,best price
1. Certificate ISO9001
2. loading capacity 20T, 40m3
3.Temperature -18°C~45°C
4. new design, super refrigeration, low temperature, less oil consumption
FEATURE&FUNCTION :
1.The refrigerator truck panels are made by advanced foam generation crafts and sandwich crafts: the panels are made by one-time hot-press process with the excellent FRP as the inner and the outer wall-plate, PU as the refrigerator material. So the refrigerator van has the characteristics of good refrigeration function, beautiful outlooks, and good strength.
2.We adopt refrigeration unit according to your temperature requirement on the box. The refrigeration unit uses the famous brand products of Carrier and Thermo King and it can adjust the temperature automatically, realizing the combination of the motive power and refrigeration. (KV300-10, KV500-10 without electric standby).
product image:
refrigerator truck
refrigerator truck
refrigerator truck
Main parameter
Product | CLW5160XLC3 refrigerator truck |
|
Cubage(T) | Container size length/width/height (mm) | 7400×2280×2400 |
Vehicle parameters | Overalldimension length/width/height (mm) | 9990×2490×3850 |
Gross weight (kg) | 16000 | |
curb weight(kg) | 6805 | |
Frontsuspension/rearsuspension (mm) | 1430/2960 | |
Approach/departure angle | 20/8 | |
Max speed | 90 | |
Vehicle Description Section | Multi-zone temperature: Xiang Ti free to the installation of side door, every folder different temperature. | |
Chassis | Chassis model | DFL5160XXYBX1 |
Wheelbase (mm) | 5600 | |
Front tread | 1880 | |
Rear tread | 1800 | |
Tyre specification | 9.00-20 | |
Fuel type | Diesel | |
Engine parameters | Engine | ISDe210 30 |
Exhaust/ Power (ml/kw) | 6700/155 | |
Engine Manufacturer | Dongfeng cummins engine Co., LTD | |
The picture and parameter mentioned above is only for reference. The Specific product will be produced according to your order
For more information about the delivery, warranty,payment,more specific details , please don't hesitate to contact with us!
International Trade Manager Rokc Hwang
Tel.0086-13886861936 0086-0722-3819709 Fax 0086-0722-3819809
Official website international
Hubei Chengli Special Automobile Co.,Ltd
Factory Address: Chengli Auto Industrial Park, Suizhou City, Hubei Province, China
