Specifications
FAW 10CBM concrete mixing concrete mix truck specifications340~440PH diesel engine for choose
capacity:10~12M3
FAW 10CBM concrete mixing concrete mix truck
Concrete trucks mixer trucks are made to transport and mix concrete up to the construction site. They can be charged with dry materials and water, with the mixing occurring during transport. With this process, the material has already been mixing. The concrete mixing transport truck maintains the material's liquid state through agitation, or turning of the drum, until delivery.
Specifications:
I. Vehicle Parameter | ||||||||||||||||
1, model,name | CA5250GJBP66K2L1T1E concrete mixer truck | |||||||||||||||
2, tanker capacity | 10 m³ | |||||||||||||||
3,manufacturer | Hubei ChengLi Special Automobile Co.,Ltd (IN CHINA) | |||||||||||||||
4, Overall dimension | 9210×2495×3900 mm | 5,curb weight | 14590 Kg | |||||||||||||
6, cab seats | 3 | 7,Max speed | 88km/h | |||||||||||||
8,Transmission | 8 forward gear,1 reverse gear | |||||||||||||||
9,Approach/departure angle | 24/18 ° | 10,front/ rear hang | 1500/2560mm | |||||||||||||
11,steering type | Left- hand drive( right-hand drive can opt) | |||||||||||||||
12,Special device | Driving system | Reducer | Italy Pump | |||||||||||||
Hydraulic pump | Italy Pump | |||||||||||||||
Hydraulic motor | Italy Pump | |||||||||||||||
Radiator | China Kaitong | |||||||||||||||
Water supplying system | Water tank capacity | 200L | ||||||||||||||
Supplying type | Atmospheric pressure | |||||||||||||||
operating type | Flexible shaft | |||||||||||||||
II. Chassis parameter | ||||||||||||||||
1, Chassis model | CA1250P66K2L1T1S2E | 2, Brand name | FAW | |||||||||||||
3,manufacturer | FAW Motor Co.,Ltd. | |||||||||||||||
4,Drive type | 6*4 | 5,Wheel base | 3800+1350 mm | |||||||||||||
6,Front track base | 2050 mm | 7,Rear track base | 1830mm | |||||||||||||
8,Tire specification | 11.00R20-16PR | 9,tyre number | 10+1(spare tyre) | |||||||||||||
10,axle load | 7000/18000 kg | 11,axle number | 3 | |||||||||||||
III. Engine parameter | ||||||||||||||||
1,engine type(emission/power) | CA6DL2-35E3( 8600ml / 370kw ) | |||||||||||||||
2, Engine manufacturer | China First Automobile Group Corporation | |||||||||||||||
3,Fuel type | Diesel | 4,Emissions standards | Euro3 | |||||||||||||
