DF Titan 10m3 Concrete Mixer Truck, Mixer Truck for Sale

Name: DF Titan 10m3 Concrete Mixer Truck, Mixer Truck for Sale
Brand: DongFeng, DongFeng
SKU: 140782040
Availability: InStock

US$ 59,000 - 65,000 MOQ: 1 Set

Key Specifications

Condition:

New, new

Place of Origin:

Hubei, China

Brand Name:

DongFeng, DongFeng

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any ports available in china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name DongFeng, DongFeng

Model Number DFL5250GJBA, DFL5250GJBA

Motor Power DTM

Mixing Power DTM

Charging Capacity DTM

Reclaiming capacity DTM

Speed of Mixing Drum DTM

Water Supply Mode DTM

Working Cycle Period Ref as below Technical Specifications

Discharge Way Automatic

Outline Dimension 8840 *2500*3930, 8840 *2500*3930

After-sales Service Provided Overseas service center available

DF Titan 10m3 concrete mixer truck, mixer truck for sale

Product Description

1.running stable

2.quality reliable
3.inner environmental comfortable
4.energy efficient
5.famous brand chassis


I. Vehicle Parameter
1	Model,name:	DFL5250GJBA CCONCRETE MIXER TRUCK
2	Tanker capacity:	10m3
3	Manufacturer:	Hubei ChengLi Special Automobile Co.,Ltd (IN CHINA)
4	Overall dimension:	8840 ×2500×3930
5	Curb weight:	13000 Kg
6	Cab seats:	2,3
7	Max speed:	80 km/h
8	Transmission:	8 forward gear, 1 reverse gear
9	Approach/ departure angle:	30/18
10	Front/ rear hang:	1460/2380 mm
11	Steering type	Left-hand drive
12	Cabin:	White(other colors are available), Flat, luxurious interior trim and seat,
		and power steering,forward flip without air conditioning,
13	Characteristics	1. Mixing tube and blade use special wear-resistant materials.
		2. Discharge mouth and the hopper use the same wear-resistant material with mixing tube.
		3. Operating system is humanized, flexible axle operating, simple, safe and reliable.
		4. Using Italy pump.Italy Pump.Reducer.Hydraulic pump,Hyd-motor
		5. Using the Configuration of domestic advanced engineL340 30, 340 horsepower EGR engine with Type(11.00R20),
		6. The material is coming out quickly, without the remainds
II. Chassis parameter
1	Chassis model	DFL5250GJBA
2	Brand name	DongFeng
3	Manufacturer	DongFeng motor Co,.Ltd
4	Drive type	6X4
5	Wheel base	3650+1350 mm
6	Front track base	1986 mm
7	Rear track base	1860 mm
8	Type specification	11.00R20
9	Type number	10+1(spare tyre)
10	Axle load	7000/18000(double axle)
11	Axle number	3
III. Engine parameter
1	Engine type (emission/power)		L340 30 (8900ML/250KW)
2	Engine manufacturer		Dongfeng Engine Co., Ltd.
3	Fuel type		Diesel
4	Emissions standards		GB17691-2005 Euro lll,GB3847-2005
