Foton 4X2 Concrete Mixer Truck for Sale

US$ 9,000 - 29,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hubei, China

Brand Name:

CLW

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5160GJBB3

Foton 4X2 concrete mixer truck for sale

Product Description

1.running stable
2.quality reliable
3.inner environmental comfortable
4.energy efficient
5.famous brand chassis

Foton concrete mixer truck specification:

Vehicle model	CLW5160GJBB3 concrete mixer truck	Batch No.	208
Manufacturer	Hubei Chengli Special automobile Co. ,Ltd(china)	Brand name	CLW
Overall dimension(mm)	7050×2490×3500	Total weight(Kg)	16000
Body internal dimension(mm)	××	Rating load(Kg)	7050
Approach/departure angle	19/10	Curb weight(Kg)	8755
Front/rear hang(mm)	1365/2085	Max speed(km/h)	85
Chassis model	BJ5163VLFHA
Engine model	Engine manufacturer	Emission	Power
YC6J190-30 YC6J190-33	Guangxi Yuchai diesel engine company	6500 6494	140 140
Fuel type	Diesel	Emission standard	EGR
Axle number	2	Tyre number	6
Wheelbase	3600	Tyre specification	10.00-20,9.00-20,9.00R20
Axle load	6000/10000	Front wheel distance	1900
Leaf spring number	10/10+9	Rear wheel distance	1847

No.	System	Name	Reference data
1	Mixing churn parameters.	Mixing volume.m³	6
		Material incoming speed m³/min	≥2.8
		Material coming out speed m³/min	≥1.2
		Residual rate %	≤0.5
		Mixing churn circling speed rpm	0~12
2	Drive system	decelerator	Keyi(China)
		hydraulic pump	Yuci(China)
		hydraulic motor	Zhenjiang Dali(China)
		Cooler	Baoying(China)
3	Water supply system	Water capacity L	450
3	Water supply system	Water supply method	Air pressure water supply
4	Operating system	Operating method	flexible shaft operating
