Dongfeng KinLand 6x4 Concrete Mixer Truck for Sale

US$ 61,000 - 70,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Hubei, China

Brand Name:

CLW

Hubei Ocean Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5250GJB3

Dongfeng KinLand 6x4 concrete mixer truck for sale

Product Description

1.running stable
2.quality reliable
3.inner environmental comfortable
4.energy efficient
5.famous brand chassis

Vehicle model	CLW5250GJB3 concrete mixer truck	Batch No.	208
Manufacturer	Hubei Chengli Special automobile Co. ,Ltd(china)	Brand name	CLW
Overall dimension(mm)	9170,9650×2500×3970	Total weight(Kg)	25000
Tanker capacity	6-10cbms	Rating load(Kg)	10820,10755
Approach/departure angle	30/13,30/12	Curb weight(Kg)	14050
Front/rear hang(mm)	1500/2520,1500/2800	Max speed(km/h)	75
Chassis model	DFL5251GJBA1
Engine model	Engine manufacturer	Emission	Power
L340 30 L375 30	Dongfeng diesel engine company	8900 8900	250 276
Fuel type	Diesel	Emission standard	EGR
Axle number	2	Tyre number	6
Wheelbase	3650+1350, 4000+1350	Tyre specification	11.00-20,9.00-20,12.00R20
Axle load	7000/18000	Front wheel distance	2027
Leaf spring number	9/10,9/13	Rear wheel distance	1820/1820,1850/1850

System	Name	Reference data
Mixing churn parameters.	Mixing volume.m³	6
	Material incoming speed m³/min	≥2.8
	Material coming out speed m³/min	≥1.2
	Residual rate %	≤0.5
	Mixing churn circling speed rpm	0~12
Drive system	decelerator	Imported from Italy
	hydraulic pump	Imported from Germany or USA
	hydraulic motor	Imported from Germany or USA
	Cooler	Changzhou(China)
