Cheap Economic Tractor Trailer Automatic Transmission

Cheap Economic Tractor Trailer Automatic Transmission thumbnail-1
Cheap Economic Tractor Trailer Automatic Transmission thumbnail-2
Cheap Economic Tractor Trailer Automatic Transmission thumbnail-3
Cheap Economic Tractor Trailer Automatic Transmission thumbnail-4
Cheap Economic Tractor Trailer Automatic Transmission thumbnail-5
Cheap Economic Tractor Trailer Automatic Transmission photo-1
Cheap Economic Tractor Trailer Automatic Transmission photo-2
Cheap Economic Tractor Trailer Automatic Transmission photo-3
Cheap Economic Tractor Trailer Automatic Transmission photo-4
Cheap Economic Tractor Trailer Automatic Transmission photo-5
US$ 4,000 - 4,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Shanghai Hoosan Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Other, Farm Tractor, garden tractor,lawn tractor
Drive Type Gear Drive
Power(W) 8.46 kW
Certificate CE
Brand Name HOOSAN
Model Number HS400
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas

Cheap economic tractor trailer automatic transmission



Product Description



Parameter of tractor trailer automatic transmission:



Technical Data
Model HS200 HS204 HS240/250 HS244/254 HS300 HS304 HS300 HS304 HS350 HS354 HS400 HS404
Type 4*2 4*4 4*2 4*4 4*2 4*4 4*2 4*4 4*2 4*4 4*2 4*4
Dimension mm
Length 2630 2700 2800 2800 2700 2800 2780 2850 2800 2900 2800 2900
Width 1260 1560 1560 1560 1560 1560 1560 1560 1560 1560 1560 1560
Height 1896 1896 1896 1896 1896 1896 1896 1896 1896 1896 1896 1896
Tread Front Wheel 1000 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Rear Wheel 1000 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Wheel Base 1560 1600 1660 1660 1660 1660 1660 1660 1690 1690 1690 1690
Min.Ground Clearance 300 300 300 300 320 300 320 300 320 300 320 300
Dry Mass kg 1100 1150 1170 1200 1150 1200 1200 1250 1200 1300 1200 1300



Engine
Model JD295 JD295 JD2100 LD385 JD2102 JD2102 LD390 LD390 LD4L22 LD4L22 LD4L23 LD4L23
Type Vertical Water Cooledand 4-stroke
Rated Power kw 14.72 14.72 17.6/18.4 17.6/18.4 22.06 22.06 22.1 22.1 25.8 25.8 29.4 29.4
Rated Rev. r/min 2300 2300 2400 2400 2400 2400 2400 2400 2400 2400 2400 2400
Fuel  Diesel  Oil
Tire
FrontWheel 4.00-16 6.00-16 5.50-16 (2WD)/6.00-16(4WD) 5.50-16(2WD)/6.00-16/6.50-16(4WD)
16(4WD)
Rear Wheel 8.30-24 9.50-24 9.50-24 9.50-24/11.2-24
Clutch  Dry-friction，single stage or Dry-friction，Two Stage
Steering Mechanical Type／Mechanical Type or Hydraulic Type
ransmission Box （4+1）×2or（4+1）×2×2（with  creeping Shift）
Suspension Type Rear three-point suspension Class 1
PTO shaft
Type and Rev  r/min Non-independent type720 or Non-independenttype540/720
Spline Size I35 Rectangle Spline With 6 teeth （6×28.91×34.79×8.69）



Overview of tractor trailer automatic transmission:

Cheap economic tractor trailer automatic transmission

Cheap economic tractor trailer automatic transmission

Cheap economic tractor trailer automatic transmission

Cheap economic tractor trailer automatic transmission



tractor trailer automatic transmission
