Specification:
Specification |
overall weight(kg) |
5600 |
L×W×H(mm) |
5950×2200×2850 |
|
rated bucket capacity(m3) |
1.1(1.4 big bucket) |
|
Rated load(kg) |
2000 |
|
Maximum dump height (mm) |
2850/3200 |
|
Dump distance |
1084 |
|
Max. breakout force(KN) |
70 |
|
Engine |
Model |
Weichai4108 |
Optional |
C u m m i n s 4BT3.9-C100 |
|
Type |
In-line arrangement, Water cooling, four-stroke |
|
Rated power(kw) |
60kw/75kw |
|
Rated speed(r/min) |
2400 |
|
Transmission system |
Model of torque converter |
YJ280 |
Type |
3-element single stage |
|
Gearbox type |
Fixed-spindle power shift |
|
Gear shift |
2 gears ahead,2 gear astern |
|
Hydraulic system |
Working pump |
CBF25 |
System working pressure |
16MPA |
|
Steering system |
Type |
Articulated hydraulic steering |
Max. turning angle |
35±1° |
|
Min turning radius(mm) |
4500 |
|
Brake system |
Brake type |
Air assisted oil disc on four wheel |
Tire |
Standard tire |
16/70-20 |
1. standard 2 ton wheel loader
2. L x W x H: 5950x2200x2850mm
* CE approved wheel loader standard ZL20 model
* Best and beautiful european design, best configuration
* Joystick & pilot control, quick hitch device, various optional attachments
* A/C, heater cab, comfortable operation environment
* New preheater on engine, suitable for cold weather
* Hot sale model
1. Streamlined ordinary and European appearance design, elegant and generous.
2. Bucket can be set level automatically, computer is adopted to optimize design, single tipping bucket cylinder, “Z” type turning bucket structure, to realize the enormous shovel digging forces.
3. Gearbox and torque converter has integral structure, realize performance.
4. The dynamical system selects the engine of WEICHAI model and Cummins model and EPA approve model, reliable performance, high efficiency and economizing on fuel.
5. Complete hydraulic changing direction system, reliable performance.
6. Can allocate many kinds of selectable assembly, to meet the needs of various working states, like pallet fork, grass fork, snow blower, snow shovel, 4 in 1 multi-function bucket, snow bucket, and so on.
Advantage & Application
1.Chinese C-ummin-s intercooled& turbocharged diesel engine;
2. Integral torque converter and gearbox(Germany ZF technology);
3. Driving axle with built-in free-wheel anti-slip differential;
4. Heavy-duty roller chains transmission balance box;
5.Popular swing-arm connecting rod operating mechanism;
6. Free-maintenance rolling-disc rotary device;
7. Double cylinders control the balde cutting angle;
8.Two sets of imported control valve (HUSCO Brand);
9. Imported hydraulic balancing valve for the blade lifting;
10. Steering system:center articulated mechanism and tilting front wheels to achieve crab-style movement;
11. Electro-hydraulic control: instrumentation monitoring & maintenance-free OPTIMA battery;
