1.5Ton Everun Electric Forklift, Radlader China, Mini Loader

Name: 1.5Ton Everun Electric Forklift, Radlader China, Mini Loader
Brand: EVERUN
SKU: 140768278
Availability: InStock

US$ 10,000 - 12,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

EVERUN

Qingdao Everun Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name EVERUN

Model Number ER-EFT15

Type Powered Pallet Truck

Power Souce AC Motor

Rated Loading Capacity 1500kg

Max. Lifting Height 4015mm

Min. Lifting Height 2115mm

Fork Length 920(1070)mm

Fork Width 100mm

Overall Dimensions 2960*1086*2115mm

Certification CE&ISO9001-2008

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Electric Forklift ER-EFT15:
1),Mini Forklift For Narrow And Small Space
2),Low Center Of Gravity, Small Turning Radius.

Specificaitons

MODEL		CPD15J
Load capacity		1500 kg
Load center		500 mm
Power type		Battery
Max.lifting speeds(with load)		285 mm/s
Max.driving speeds(with/without load)		12.5/14 km/h
Max towering (with load)		6.5 kn
Grade ability(with load)		15%
Lifting height		3000 mm
Free lift		60 mm
Tilting angles (forwardα-backwardβ)		6°/12°
Min. turning radius		1820 mm
Min. Right angle aisle width		1810 mm
Min.under-clearance		95 mm
Dimensions	Overall length(including fork)	2960 mm
	Overall width	1086 mm
	Overall height(mast lowered)	2115 mm
	Overall height(mast extended)	4015 mm
Overall height to overhead guard		2115 mm
Fork width		100 mm
Fork thickness		35 mm
Fork length		1000 mm
Fork overhang		436 mm
Wheel base		1250 mm
Tread	Front tread	900 mm
	Rear tread	920 mm
Tire	Front tire	6.50-10
	Rear tire	5.00-8
Total weight		3050 kg
Motor	Traction motor	XQ-5-4A3
	Lifting motor	XQD-7.5-3C
Battery	Battery type	D-440
	Battery voltage/capacity	48V/440Ah
