Generator Automatic Transfer Switch ATS

Specifications

1 Ensure the abovementioned requirements are correctly satisfied;

2 Switch off the air circuit breaker (NO. 1) on the panel;

3 Turn the start-up key (NO. 5) clock wise to the START position so that the starting motor could start up the engine within 3-10 seconds. Turn the key to OPERATION position after startup and then the Gen-set is on power generating status.

4 Switch on the air circuit breaker (serial number 1) and the V-meter on the panel displays the magnitude of voltage.

If the startup process fails, repeat the procedure second or third times, with an interval of minimum 15 seconds. If all the 3 start-up trials fail, the fault indicator (NO. 9) will light up. Then it need to check and find out the fault cause, and remove the faults before next round of start-up.

5 Keep the Gen-set running idly for 5-10 minutes after successful startup.

6 Turn the start-up key (NO. 5) to the OFF position. The power accelerograph turns off automatically and the Gen-set shuts down. Trial operation is completed.
