Yanmar type 1800RPM Diesel engine 186FS

Model

YM186FS

Type

Single-cylinder,vertical,4-stroke air-cooled diesel engine

Combustion system

Direct lnjection

Bore X Stroke(mm)

86x70

Displacement(cc)

406

Engine Speed(rpm)

1500

1800

Max.output(kw)

6

6.3

Rated output(kw)

5.7

6

Fule

0# or -10# light diesel fuel

Fule oil tank volume(L)

5.5

Lubricatiom oil volume(L)

1.65

Fule oil consumption rate(g/kw.h)

275.1

281.5

Valve clearance (mm)

0.10-0.15

PTO Model

Camshaft

Starting system

Recoil or Electric

PTO rotation direction

It is clockwise as viewing from the flywheel end

Battery

Optional

Dimension(mm)

522x522x578

Net weight(kg)

45

20FT

220

We reserve the right to change specifications without notice
