Diesel Water Pump KDP20/KDP30/KDP40

Model

DP20

Suction,discharge port diameter[mm(in)]

50(2")

Rated total head (m)

15

Max. total head (m)

26

Self-priming time (s/4m)

80

Max suction head (m)

8

Cont.capacity (m3/hr)

22

Max. capacity (m3/hr)

36

Fuel tank Capacity (L)

2.5

Enigine model

YM170F

Type

Single-cylinder,Direct injection,vertical,4-stroke air-cooled diesel

Bore X Stroke (mm)

70×55

Fuel

Summer:0# Winter: -10#

Lubricatiom Oil Model

SAE10W-30(above CD grade)

Lubricatiom oil volume (L)

0.75

Fule oil consumption rate(g.kw/h)

517

Displacement (L)

0.211

Power/ speed:KW, r/min

2.8/3600

Compression Ratio:

20

Noise level(dB(A)/7m)

74

alert

Yes

Connecter of infall,Connect of outfall

Yes

Fiffer

Yes

Seal ring

Yes

Hoop

Yes

Dimension:mm

520×440×560

Dry weight (kg)

35

20FT

220

Luxury big fuel tank

optional

             Electrical start

optional

               30Ah MF Battery

optional

We reserve the right to change specifications without notice
