Small portable electric air-cooled diesel generator

Model

KDE3500E

Frequency (HZ)

50

60

Rated Output (KVA)

2.8

3.0

Maximum Output (KVA)

3.0

3.2

Rated Voltage (V)

115/230

120/240

Rated current (A)

24.4/12.2

25/12.5

Rated rotation speed (rpm)

3000

  3600

Phase No.

Single phase

Power Factor

  1.0

Excitation Mode

Self-excitation, 2 pole and constant voltage (AVR)

DC Output

12V. /8.3A  , Terminal Post

Noise Level (7m) dB(A)

72

Engine Model

  KM178FE

Engine type

Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel

Bore × Stroke(mm)

78 x 62

Displacement (L)

0.296

Rated Power KW

3.68/3000

4.0/3600

Fuel comsumption Rate(g. kw/h)

276.1

285.6

Compression Ratio

20: 1

Lubrication System

Pressure Splashed

Starting System

  Electric Start with 30Ah MF battery

Fuel Type

0#(summer)-10#(winter) diesel

Lube Oil Brand

  SAE10W30 (above CD Grade)

Lube Capacity (L)

1.1

Fuel Tank Capacity (L)

12.5

Continuous Running Time (hr)

12

Overall Dimension: LxWxH (mm)

710 x 500 x 590

Dry Weight (Kg)

70

Quantity in 20FT

132 Pcs

Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel

We reserve the right to change specifications without notice
