3inch 6.0HP KDP30 Powered by Diesel Engine 178F Small Water Pump

Name: 3inch 6.0HP KDP30 Powered by Diesel Engine 178F Small Water Pump
Brand: SUMOKAMA
SKU: 140760616
Availability: InStock

Changzhou Yarmax Power Co., Ltd.

Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

SUMOKAMA

Model Number:

KDP30

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name SUMOKAMA

Model Number KDP30

Theory Other

Structure Other

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Diesel

Pressure Low Pressure

Application Other

Specifications

1. Driven by super light diesel engine.
2. Self-suction structure.
3. Die-casted aluminum pump

Model	KDP30
Suction, discharge port diameter[mm(in)]	80(3" )
Rated total head (m)	13
Max. total head (m)	25
Self-priming time (s/4m)	120
Max suction head (m)	8
Cont. capacity (m3/hr)	30
Max. capacity (m3/hr)	55
Fuel tank Capacity: L	3.5
Enigine model	KM178F
Type	Single-cylinder, vertical, 4-stroke air-cooled diesel engine
Bore X Stroke (mm)	78× 62
Fuel	Summer: 0# Winter: -10#
Lubricatiom Oil Model	SAE10W-30(above CD grade)
Lubricatiom oil volume: L	1.1
Fule oil consumption rate(g. kw/h)	441
Displacement: L	0.296
Power/ speed: KW, r/min	4/3600
Compression Ratio:	20
Noise level(dB(A)/7m)	74
Oil alert	Yes
Connecter of infall, Connect of outfall	Yes
Fiffer	Yes
Seal ring	Yes
Hoop	Yes
Dimension: mm	590× 480× 585
Dry weight: kg	48
20FT	192
Luxury big fuel tank	optional
Electrical start	optional
30Ah MF Battery	optional
We reserve the right to change specifications without notice
