Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Electrical Generator
US$ 2,000 - 8,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
cummins
Model Number:
HCM143
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Silent Diesel Genset/ Energy Generatorsprice From China SupplierUS$ 2,000 - 10,000MOQ: 1 Piece -
Weichai Silent Diesel Generator for Sale From China SupplierUS$ 2,000 - 10,000MOQ: 1 Piece
-
HOT SALE!!! Air Cooled Diesel Generator Open Type KDE2500EUS$ 330 - 350MOQ: 10 Sets
-
HOT SALE!!! Air Cooled Diesel Generator Open Type KDE3500EUS$ 380 - 420MOQ: 10 Sets
-
HOT SALE!!! Air Cooled Diesel Generator Open Type DG6LEUS$ 430 - 460MOQ: 10 Sets
Place of Origin
Jiangsu, China
Brand Name
cummins
Model Number
HCM143
Output Type
AC Three Phase
Speed
1500
Frequency
50
Rated Power
104kw
Rated Voltage
400/230V
Specifications
1)Cummins engine as the main power2)Original stamford,leroy somer and Marthon alternator
3)Prompt delievry
| Generator set | Genset Model | HCM143 | |
| Rating Power (KW/KVA) | 104/130 | ||
| Standby Power(KW/KVA) | 114/142.5 | ||
| Rating Ammeter(A) | 187 | ||
| Diesel engine | General data | Engine model | 6BTAA5.9-G2 |
| Prime Power(KW/HP) | 120/163 | ||
| Standby Power(KW/HP) | 132/180 | ||
| number of Cylinder & Configuration | 6 cylinders in line | ||
| Bore X Stroke (mm) | 102X120 | ||
| Displacement(l) | 5.9 | ||
| Compression Ratio | 16.5:1 | ||
| Governor type | Electronic governor | ||
| Rated RPM | 1500 | ||
| Exhaust system | Exhaust gas flow(m³/min) | 25 | |
| Max. Exhaust back Pressure(KPA) | 10 | ||
| Air intake system | Aspiration Type | Turbo & Air-Air cooled | |
| Max. intake depression(mbar) | 6 | ||
| Combustion air Volume(m³/min) | 8.2 | ||
| Fuel system | Rating Fuel Consumption(l/h) | 30 | |
| 75% full Fuel Consumption(l/h) | 30.5 | ||
| Lubrication system | Total oil capacity(l) | 16.4 | |
| Oil pressure at rated rpm(KPA) | 345 | ||
| Cooling system | Total Coolant capacity(l) | 26 | |
| Fan cooling air flow(m³/min) | 210 | ||
| Alternator | Alternator model | MGA270-104-4S | |
| Rating Voltage(V) | 400/230 | ||
| Rating Capacity(KW/KVA) | 104/130 | ||
| Eff.% | 91.6% | ||
| Power Factor | 0.8 | ||
| Exciting type | Brushless self-exciter AVR | ||
| Voltage regulation | ±1% | ||
| No. of Phase | 3 phase 4 wire | ||
| Enclosure Class | IP121 | ||
| Class of Insulation | H | ||
| Battery | Rating Capacity(AH) | 2X100AH 12V | |
| Dimension | Generator set dimension (LXWXH) | 2400x830x1430 | |
| Weight | Generator set Net Weight (kg) | 1700 | |
