5KW Open Type Diesel Generator With Wheels

Model

KDE2500E

Frequency (HZ)

50

60

Rated Output (KVA)

1.7

2.0

Maximum Output (KVA)

2.0

2.2

Rated Voltage (V)

115/230

120/240

Rated current (A)

14.8/7.4

16.7/8.3

Rated rotation speed (rpm)

3000

 3600

Phase No.

Single phase

Power Factor

  1.0

Excitation Mode

Self-excitation, 2 pole and constant voltage (AVR)

DC Output

12V./8.3A ,Terminal Post

Noise Level (7m) dB(A)

77

Engine Model

 KM170FE

Engine type

Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel

Bore × Stroke(mm)

70 x 55

Displacement (L)

0.211

Rated Power KW

2.5/3000

2.8/3600

Fuel comsumption Rate(g.kw/h)

280.2

288.3

Compression Ratio

20:1

Lubrication System

Pressure Splashed

Starting System

  Electric Start with 30Ah MF battery

Fuel Type

0#(summer)-10#(winter) diesel

Lube Oil Brand

  SAE10W30 (above CD Grade)

Lube Capacity (L)

0.75

Fuel Tank Capacity (L)

12.5

Continuous Running Time (hr)

20

Overall Dimension: LxWxH (mm)

660 x 500 x 570

Dry Weight (Kg)

60

Quantity in 20FT

 132 Pcs

Optiomal Features: Remote,ATS(Auto Transfer Switch) ,Digital Panel

We reserve the right to change specifications without notice
