PORTABLE SILENT DIESEL GENERATOR

Name: PORTABLE SILENT DIESEL GENERATOR
Brand: Sumokama
SKU: 140760188
Availability: InStock

Changzhou Yarmax Power Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Sumokama

Model Number:

All kinds of type

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number All kinds of type

Output Type AC Single Phase

Speed 3000/3600rmp

Frequency 50/60hz

Specifications

silent diesel generator 3kva
Different kind of brand engine
Floating power

Model		KDE3700T-A
Frequency (HZ)		50	60
Rated Output (KVA)		2.8	3.0
Maximum Output (KVA)		3.0	3.2
Rated Voltage (V)		115/230	120/240
Rated current (A)		24.4/12.2	25/12.5
Rated rotation speed (rpm)		3000	3600
Phase No.		Single phase
Power Factor		1.0
Excitation Mode		Self-excitation, 2 pole and constant voltage (AVR)
DC Output		12V./8.3A ,Terminal Post
Structure Type		Soundproof
Noise Level (7m) dB(A)		72
Engine Model		KM178F
Engine type		Single-Cylinder, Vertical, Four-Stroke, Direct Injection,Air Cooled Diesel
Bore × Stroke(mm)		78 x 62
Displacement (L)		0.296
Rated Power KW		3.68/3000	4.0/3600
Fuel comsumption Rate(g.kw/h)		276.1		285.6
Compression Ratio		20:1
Lubrication System		Pressure Splashed
Starting System		Electric Start with 30Ah MF battery
Fuel Type		0#(summer)-10#(winter), diesel
Lube Oil Brand		SAE10W30 (above CD Grade)
Lube Capacity (L)		1.1
Fuel Tank Capacity (L)		15
Continuous Running Time (hr)		12
Overall Dimension: LxWxH (mm)		955 x 560 x 780
Dry Weight (Kg)		140
Quantity in 20FT		72 Pcs
Optiomal Features:
ATS	Optional
Digital Panel	Optional
Remote control	Optional
We reserve the right to change specifications without notice
