Air Cooled Diesel Engine

Model

YM170F

Type

Single-cylinder,vertical,4-stroke air-cooled diesel engine

Combustion system

Direct lnjection

Bore X Stroke(mm)

70x55

Displacement(L)

0.211

Model

YM170F

Engine Speed (rpm)

3000

3600

Max.output(kw)

2.8

3.1

Rated output(kw)

2.5

2.8

Fule

0# or -10# light diesel fuel

Fule oil tank volume(L)

2.5

Lubricatiom oil volume(L)

0.75

Fule oil consumption rate(g/kw.h)

280.2

288.3

Valve clearance (mm)

0.10-0.15

PTO Model

Crankshaft orCamshaft

Starting system

Recoil or Electric

PTO rotation direction

It is clockwise as viewing from the flywheel end

Battery

Optional

Dimension(mm)

435x380x473

Net weight(kg)

28

20FT

350

We reserve the right to change specifications without notice
