Water Cooled Diesel engine S195,ZS1100,ZS1110,ZS1115,ZS1125,ZS1130

Model

         ZS195/ZS195D/ZS195ND/ZS195WP

Type

Single cylinder, horizontal, 4-strokes, water-cooled

Combustion system

Direct injection

Bore×stroke

95×115

Total Displacement

0.815

Compression ratio

17

1-hour rated output(kW/min)

10.6/2000

12-hour rated output(kW/min)

9.7/2000

Specific fuel consumption(g/kW.h)

≤244.8

Specific lube oil consumption(g/kW.h)

≤ 2.72

Cooling method

Hopper type Water-cooled or Radiator

Lubrication method

Combined pressure and splash

Starting method

Hand cranking or Key Start

Net weight (kg)

145/151/158/166/151

Overall dim (L×W×H) (mm)

900*440*760

Quantity in 20FT (Sets)

96
