third generation sand making machine widely used in mining industry
Our third generation sand making machine is especially efficient to crush harder and causticity materials, such as carborundum, emery, and magnesium sand. Zenith B Series third generation sand making machine is one of the most advanced impact crushers nowadays. It introduces high quality roller bearings, which ensure the smooth running of main unit. Personalized design is used in upper cap, third generation sand making machine is easy and convenient to maintain and replace spare parts. third generation sand making machine is our sole patent using central feeding & central cascade feeding, which can be changed based on customers' needs.
third generation sand making machine working principle
The entire center feeding: Material falls the feed hopper, then enters the high-speed rotary sling wheel from center feeding hole, which is speeded immediately in the sling wheel. The speed can reach several dozens times of the gravity acceleration. Then third generation sand making machine is thrown from the sling wheel. First, it is crushed with other rebounded material fell freely from the sling wheel. Then both of them are impacted to the material lining (rock-rock) or strike back block (rock-iron), rebounded and stroke to the top of eddy cavity of third generation sand making machine in the inclined-up direction. Then it moves along deflection-down, and forms a continuous material curtain with the material from the impellers passage. Just like this, the material is stroke, rubbed, crushed twice or more, then is discharged from the down discharging hole.
third generation sand making machine Features:
1. The structure is simple, and the operating cost is low.
2. High efficiency, and low consumption.
3.third generation sand making machine is slightly influenced by the humidity of material, and the max humidity is 8%.
4. third generation sand making machine is more suitable for crushing mid-hardness materials and high-hardness materials.
5. Its product is cubic, and the density of piling up is high and the iron pollution is low.
6. The working noise is less than 75 decibels and dust pollution is little
third generation sand making machine specifications:
model |
Feeder Opening
(mm)
|
Feeding
Size (mm)
|
Output size
(mm)
|
Output size
(mm)
|
Capacity t/h |
Motor
(kw)
|
||
Clinker |
limestone |
Siliceous sand |
||||||
800×400 |
400×185 |
120 |
≤5 |
5-20 |
20-30 |
30-45 |
35-45 |
22-37 |
800×600 |
500×250 |
180 |
≤5 |
5-20 |
35-40 |
40-55 |
45-55 |
37-45 |
800×800 |
550×330 |
180 |
≤5 |
5-20 |
35-45 |
60-65 |
55-65 |
37-45 |
1010×1010 |
1000×350 |
180 |
≤5 |
5-20 |
45-55 |
60-75 |
65-75 |
45-55 |
1200×1000 |
1200×400 |
180 |
≤5 |
5-20 |
80-110 |
80-100 |
80-100 |
90-110 |
1200×1200 |
1200×450 |
180 |
≤5 |
5-20 |
100-110 |
90-100 |
90-120 |
110-132 |
1400×1400 |
1500×500 |
190 |
≤5 |
5-20 |
100-150 |
100-150 |
120-150 |
160 |
1600×1600 |
1600×550 |
190 |
≤5 |
5-20 |
170-210 |
190-250 |
190-250 |
250 |
1800×1800 |
1800×800 |
190 |
≤5 |
5-20 |
250-270 |
280-310 |
280-310 |
280 |
Sand making machine picture show:
Sand making line:
Inner structure:
We have developed long and good relationship with many shipping agents. Ocean freight partners are: APL, COSCO, OOCL, CSCL, MSC, etc. and train shipping is also available. The perfect shipping way and best service with lowest price are always provided for customers.
1.Pre-sale services:
1)Selecting equipment type;
2)Designing and fabricating the products in accordance with the special requirements of the clients;
3)Training technical personnel for our clients;
4)Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects
2.Services provided during the sale:
1)Checking products acceptance ahead of delivery;
2)Introducing the service system to our clients.
3. After-sale services:
1)Installing and testing the equipments;
2)Training the first-line operators on site;
3)Distributing the guarantee fittings door-to-door;
Zhengzhou Huahong Machinery Equipment Co, Ltd is a company that produce large and medium-sized crushers and mills and many other mineral equipment Our company is located in Zhengzhou,henan province. Our main products are crushers, raymond mill, rotary dryer, grinding mills, vibrating feeder, vibrating screen and so on. All these machines have bben used in various fields, such as mining, chemical industry, metallurgy, coal, and fire resistant materials.
The company owns a large group of excellent crews that represent the authority of management and research. And they absord the advanced management method of domestic and overseas positivly. Now, the company has developed more and more perfect. We hope that we can provide customers more good products and we still keep learning.
Certification:
If you are interested in our products, please contact us, we will give you the most favorable price, welcome to visit the factory.
