SJH YTO Engine 70HP Farm Agtriculture Tractor Without Cab

Model

SJH700/750/800B/850B/900

SJH704/754/804/854/904

Type

2WD

4WD

Parame-ter data

Overall Dimension

Length(mm)(inc.Front counterweight and rear suspension)

4070

4080

Width(mm)(outside tire

in case of the common tread)

1900

Height(mm)(up to the top of muffle)

2700

2740

Tread

Front wheel(mm)

1400,1500(normal),1600,1700

1450

Adjustment

adjustable

fixed

Rear wheel(mm)

1430,1530(normal),1630,1730,1830

Adjustment

Step adjustment

wheelbase(mm)

2260

2270

Min .ground clearance (mm)

450(at the front shaft tie rod)

400(at front transaxle)

Min.turining radius(mm)

single sided brake is not used

4.2

5.1

single sided brake is used

3.6

4.6

Nominal traction force(kN)

13.5/14.5/15.5/17/17.5

15/16/17/18/19

Power of the PTO shaft(KW)

46.4/49.5/53.1/56.3/59.5

Structure mass

With the cab(kg)

2700

2880

Without the cab(kg)

2660

2840

Least used mass

With the cab(kg)

2880

3070

Without the cab(kg)

2840

3030

Counter

weight

Front counterweight(kg)

220

Rear counterweight(kg)

300

Quality Distribu-tion

Front wheel

With the cab(kg)

1160

1340

Without the cab(kg)

1160

1340

Rear wheel

With the cab(kg)

1720

1730

Without the cab(kg)

1680

1690

Gearshift

F10+R10,shuttling shift

Theory

Speed

(Km/h)

Forward

Low

Ⅰ

3.06

Ⅱ

4.10

Ⅲ

5.08

IV

6.50

V

8.75

High

Ⅰ

11.01

Ⅱ

14.75

Ⅲ

18.28

IV

23.40

V

31.49

Reverse

Low

Ⅰ

2.59

Ⅱ

3.47

Ⅲ

4.30

IV

5.50

V

7.40

High

Ⅰ

9.32

Ⅱ

12.48

Ⅲ

15.47

IV

19.8

V

26.64
