SJH 75HP 4WD Farm Agtriculture Tractor With Best Price
SJH 75HP 4WD farm agtriculture tractor with best price
Model |
SJH700/750/800B/850B/900 |
SJH704/754/804/854/904 |
|||||
Type |
2WD |
4WD |
|||||
|
Parame-ter data
|
Overall Dimension |
Length(mm)(inc.Front counterweight and rear suspension) |
4070 |
4080 |
|||
|
Width(mm)(outside tire in case of the common tread) |
1900 |
||||||
Height(mm)(up to the top of muffle) |
2700 |
2740 |
|||||
Tread |
Front wheel(mm) |
1400,1500(normal),1600,1700 |
1450 |
||||
Adjustment |
adjustable |
fixed |
|||||
Rear wheel(mm) |
1430,1530(normal),1630,1730,1830 |
||||||
Adjustment |
Step adjustment |
||||||
wheelbase(mm) |
2260 |
2270 |
|||||
|
Min .ground clearance (mm)
|
450(at the front shaft tie rod) |
400(at front transaxle) |
|||||
Min.turining radius(mm) |
single sided brake is not used |
4.2 |
5.1 |
||||
single sided brake is used |
3.6 |
4.6 |
|||||
Nominal traction force(kN) |
13.5/14.5/15.5/17/17.5 |
15/16/17/18/19 |
|||||
Power of the PTO shaft(KW) |
46.4/49.5/53.1/56.3/59.5 |
||||||
Structure mass |
With the cab(kg) |
2700 |
2880 |
||||
Without the cab(kg) |
2660 |
2840 |
|||||
Least used mass |
With the cab(kg) |
2880 |
3070 |
||||
Without the cab(kg) |
2840 |
3030 |
|||||
|
Counter weight |
Front counterweight(kg) |
220 |
|||||
Rear counterweight(kg) |
300 |
||||||
Quality Distribu-tion |
Front wheel |
With the cab(kg) |
1160 |
1340 |
|||
Without the cab(kg) |
1160 |
1340 |
|||||
Rear wheel |
With the cab(kg) |
1720 |
1730 |
||||
Without the cab(kg) |
1680 |
1690 |
|||||
Gearshift |
F10+R10,shuttling shift |
||||||
|
Theory Speed (Km/h) |
Forward |
Low |
Ⅰ |
3.06 |
|||
Ⅱ |
4.10 |
||||||
Ⅲ |
5.08 |
||||||
IV |
6.50 |
||||||
V |
8.75 |
||||||
High |
Ⅰ |
11.01 |
|||||
Ⅱ |
14.75 |
||||||
Ⅲ |
18.28 |
||||||
IV |
23.40 |
||||||
V |
31.49 |
||||||
Reverse |
Low |
Ⅰ |
2.59 |
||||
Ⅱ |
3.47 |
||||||
Ⅲ |
4.30 |
||||||
IV |
5.50 |
||||||
V |
7.40 |
||||||
High |
Ⅰ |
9.32 |
|||||
Ⅱ |
12.48 |
||||||
Ⅲ |
15.47 |
||||||
IV |
19.8 |
||||||
V |
26.64 |
||||||
